Trane BACnet BCI-R User Manual

BAS-SVP09B-EN 35
Object Data Points and Diagnostic Data Points
Table 12. Notification Classes
Notification Class Severity
Class 001 Critical
Class 002 Service Required
Class 003 Advisory
Class 004 Information
Table 13. Diagnostic Objects Sorted by Object Name
Object Identifier
Binary Input (BI)
Object Name Description Notification Class
Binary Input, 59 Diagnostic: Auto - SA High Press Limit Diagnostic: Auto - SA High Press Limit 002 – Service Required
Binary Input, 271 Diagnostic: CO2 Low Limit Setpoint Fault Diagnostic: CO2 Low Limit Setpoint Fault 004 – Information
Binary Input, 83 Diagnostic: CO2 Sensor Failure Diagnostic: CO2 Sensor Failure 002 – Service Required
Binary Input, 257 Diagnostic: CO2 Setpoint Failure Diagnostic: CO2 Setpoint Failure 004 – Information
Binary Input, 45 Diagnostic: Coil Temp Sensor 1 Fail Diagnostic: Coil Temp Sensor 1 Fail 1 002 – Service Required
Binary Input, 46 Diagnostic: Coil Temp Sensor 2 Fail Diagnostic: Coil Temp Sensor 2 Fail 002 – Service Required
Binary Input, 269 Diagnostic: Comp 1 Disable Input HPC Diagnostic: Comp 1 Disable Input HPC 004 – Information
Binary Input, 244 Diagnostic: Comp 1 Disable Input LPC Diagnostic: Comp 1 Disable Input LPC 004 – Information
Binary Input, 270 Diagnostic: Comp 2 Disable Input HPC Diagnostic: Comp 2 Disable Input HPC 004 – Information
Binary Input, 245 Diagnostic: Comp 2 Disable Input LPC Diagnostic: Comp 2 Disable Input LPC 004 – Information
Binary Input, 47 Diagnostic: Compressor 1 HPC Lockout Diagnostic: Compressor 1 HPC Lockout 001 – Critical
Binary Input, 43 Diagnostic: Compressor 1 LPC Lockout Diagnostic: Compressor 1 LPC Lockout 001 – Critical
Binary Input, 48 Diagnostic: Compressor 2 HPC Lockout Diagnostic: Compressor 2 HPC Lockout 001 – Critical
Binary Input, 44 Diagnostic: Compressor 2 LPC Lockout Diagnostic: Compressor 2 LPC Lockout 001 – Critical
Binary Input, 297 Diagnostic: DCV Min Position at Minimum Fan Speed
Diagnostic: DCV Min Position at Minimum Fan
Speed
004 – Information
Binary Input, 293 Diagnostic: DCV Min Position Setpoint Fail Diagnostic: DCV Min Position Setpoint Fail 004 – Information
Binary Input, 252 Diagnostic: Default Defrost Flag Diagnostic: Default Defrost Flag 004 – Information
Binary Input, 287 Diagnostic: Defrost Default Mode Ckt 1 Diagnostic: Defrost Default Mode Ckt 1 004 – Information
Binary Input, 283 Diagnostic: Defrost Default Mode Ckt 2 Diagnostic: Defrost Default Mode Ckt 2 004 – Information
Binary Input, 125 Diagnostic: Dehumid Setpoint Failure Diagnostic: Dehumid Setpoint Failure 002 – Service Required
Binary Input, 248 Diagnostic: Demand Defrost Fault A Diagnostic: Demand Defrost Fault A 004 – Information
Binary Input, 284 Diagnostic: Demand Defrost Fault A Ckt 1 Diagnostic: Demand Defrost Fault A Ckt 1 004 – Information
Binary Input, 280 Diagnostic: Demand Defrost Fault A Ckt 2 Diagnostic: Demand Defrost Fault A Ckt 2 004 – Information
Binary Input, 249 Diagnostic: Demand Defrost Fault B Diagnostic: Demand Defrost Fault B 004 – Information
Binary Input, 285 Diagnostic: Demand Defrost Fault B Ckt 1 Diagnostic: Demand Defrost Fault B Ckt 1 004 – Information
Binary Input, 281 Diagnostic: Demand Defrost Fault B Ckt 2 Diagnosti: Demand Defrost Fault B Ckt 2 004 – Information
Binary Input, 250 Diagnostic: Demand Defrost Fault C Diagnostic: Demand Defrost Fault C 004 – Information
Binary Input, 286 Diagnostic: Demand Defrost Fault C Ckt 1 Diagnostic: Demand Defrost Fault C Ckt 1 004 – Information
Binary Input, 282 Diagnostic: Demand Defrost Fault C Ckt 2 Diagnostic: Demand Defrost Fault C Ckt 2 004 – Information
Binary Input, 251 Diagnostic: Demand Defrost Fault D Diagnostic: Demand Defrost Fault D 004 – Information
Binary Input, 298
Diagnostic: Design Min Position at Midpoint Fan Speed
Fail
Diagnostic: Design Min Position at Midpoint Fan
Speed Fail
004 – Information
Binary Input, 296
Diagnostic: Design Min Position at Minimum Fan Speed
Fail
Diagnostic: Design Min Position at Minimum Fan
Speed Fail
004 – Information
Binary Input, 294 Diagnostic: Design Min Position Setpoint Fail Diagnostic: Design Min Position Setpoint Fail 004 – Information
Binary Input, 76 Diagnostic: Dirty Filter Diagnostic: Dirty Filter 003 – Advisory
Binary Input, 289 Diagnostic: Discharge Air Heat Setpoint Failure Diagnostic: Discharge Air Heat Setpoint Failure 004 – Information
Binary Input, 264 Diagnostic: Economizer Actuator Fault Diagnostic: Economizer Actuator Fault 004 – Information
