36 BAS-SVP09B-EN
Object Data Points and Diagnostic Data Points
Binary Input, 107 Diagnostic: Entering Evap Temp Sensor Fail Diagnostic: Entering Evap Temp Sensor Fail 002 – Service Required
Binary Input, 295 Diagnostic: Enthalpy Setpoint Fail Diagnostic: Enthalpy Setpoint Fail 004 – Information
Binary Input, 40 Diagnostic: Exhaust Fan Proving Failure Diagnostic: Exhaust Fan Proving Failure 001 – Critical
Binary Input, 288 Diagnostic: Exhaust Fan Setpoint Failure Diagnostic: Exhaust Fan Setpoint Failure 004 – Information
Binary Input, 151 Diagnostic: External Auto-Stop Diagnostic: External Auto-Stop 004 – Information
Binary Input, 39 Diagnostic: Fan Failure Diagnostic: Fan Failure 001 – Critical
Binary Input, 259 Diagnostic: Flame Rollout Switch Open Diagnostic: Flame Rollout Switch Open 004 – Information
Binary Input, 262 Diagnostic: Flame Sensed with Gas Valve Off Diagnostic: Flame Sensed with Gas Valve Off 004 – Information
Binary Input, 256 Diagnostic: Freezestat Tripped Diagnostic: Freezestat Tripped 004 – Information
Binary Input, 247 Diagnostic: FroStat Trip Diagnostic: FroStat Trip 004 – Information
Binary Input, 263 Diagnostic: Gas Heat Module Failure Diagnostic: Gas Heat Module Failure 004 – Information
Binary Input, 51 Diagnostic: Heat Failure Diagnostic: Heat Failure 003 – Advisory
Binary Input, 258 Diagnostic: Heating High Temp Limit Open Diagnostic: Heating High Temp Limit Open 004 – Information
Binary Input, 290 Diagnostic: IGN1 Communications Timed out Diagnostic: IGN1 Communications Timed out 004 – Information
Binary Input, 291 Diagnostic: IGN2 Communications Timed out Diagnostic: IGN2 Communications Timed out 004 – Information
Binary Input, 260 Diagnostic: Inducer Proving Switch Fail Diagnostic: Inducer Proving Switch Fail 004 – Information
Binary Input, 34 Diagnostic: Local Cool Setpoint Fail Diagnostic: Local Cool Setpoint Fail 002 – Service Required
Binary Input, 38 Diagnostic: Local Emergency Stop Initiated Diagnostic: Local Emergency Stop Initiated 001 – Critical
Binary Input, 35 Diagnostic: Local Zone Heat Setpoint Fail Diagnostic: Local Zone Heat Setpoint Fail 002 – Service Required
Binary Input, 147 Diagnostic: Maintenance Required Diagnostic: Maintenance Required 002 – Service Required
Binary Input, 242 Diagnostic: Min OA Flow Setpoint Fail Diagnostic: Min OA Flow Setpoint Fail 002 – Service Required
Binary Input, 95 Diagnostic: Mixed Air Temp Sensor Failure Diagnostic: Mixed Air Temp Sensor Failure 002 – Service Required
Binary Input, 279 Diagnostic: Mod Dehumid Config Error Diagnostic: Mod Dehumid Config Error 004 – Information
Binary Input, 239 Diagnostic: Morning Warmup Setpoint Fail Diagnostic: Morning Warmup Setpoint Fail 002 – Service Required
Binary Input, 261 Diagnostic: No Flame Sensed on heat call Diagnostic: No Flame Sensed on heat call 004 – Information
Binary Input, 37 Diagnostic: OA Humidity Sensor Failure Diagnostic: OA Humidity Sensor Failure 002 – Service Required
Binary Input, 32 Diagnostic: OA Temperature Sensor Fail Diagnostic: OA Temperature Sensor Fail 002 – Service Required
Binary Input, 58 Diagnostic: Return Air Humidity Sensor Fail Diagnostic: Return Air Humidity Sensor Fail 002 – Service Required
Binary Input, 57 Diagnostic: Return Air Temp Sensor Fail Diagnostic: Return Air Temp Sensor Fail 002 – Service Required
Binary Input, 274 Diagnostic: RTAM Comm Fail Diagnostic: RTAM Comm Fail 004 – Information
Binary Input, 276 Diagnostic: RTCM Comm Fail Diagnostic: RTCM Comm Fail 004 – Information
Binary Input, 277 Diagnostic: RTDM Comm Fail Diagnostic: RTDM Comm Fail 004 – Information
Binary Input, 273 Diagnostic: RTEM Comm Fail Diagnostic: RTEM Comm Fail 004 – Information
Binary Input, 29 Diagnostic: RTM Zone Temp Sensor Failure Diagnostic: Zone Temp Sensor Failure 002 – Service Required
Binary Input, 272 Diagnostic: RTOM Comm Fail Diagnostic: RTOM Comm Fail 004 – Information
Binary Input, 275 Diagnostic: RTVM Comm Fail Diagnostic: RTVM Comm Fail 004 – Information
Binary Input, 267 Diagnostic: SA Pressure Dead Band Failure Diagnostic: SA Pressure Dead Band Failure 004 – Information
Binary Input, 268 Diagnostic: SA Pressure PWM Fault Diagnostic: SA Pressure PWM Fault 004 – Information
Binary Input, 54 Diagnostic: SA Pressure Setpoint Failure Diagnostic: SA Pressure Setpoint Failure 002 – Service Required
Binary Input, 123 Diagnostic: SA Reheat Setpoint Failure Diagnostic: SA Reheat Setpoint Failure 002 – Service Required
Binary Input, 265 Diagnostic: SA Reset Amount Failure Diagnostic: SA Reset Amount Failure 004 – Information
Binary Input, 266 Diagnostic: SA Reset Setpoint Failure Diagnostic: SA Reset Setpoint Failure 004 – Information
Binary Input, 74 Diagnostic: SA Temp Cool Setpoint Fail Diagnostic: SA Temp Cool Setpoint Fail 002 – Service Required
Binary Input, 75 Diagnostic: SA Temp Heat Setpoint Fail Diagnostic: SA Temp Heat Setpoint Fail 002 – Service Required
Binary Input, 246 Diagnostic: Smoke Detector Diagnostic: Smoke Detector 004 – Information
Binary Input, 106 Diagnostic: Space Humidity Sensor Fail Diagnostic: Space Humidity Sensor Fail 002 – Service Required
Table 13. Diagnostic Objects Sorted by Object Name (continued)
Object Identifier
Binary Input (BI)
Object Name Description Notification Class
