6
18-HH32D1-1C-EN
RReemmoovvaall IInnssttrruuccttiioonnss::
1. Remove four screws that attach the plastic top to the four support
clips on the adapter ring, and then remove the plastic top.
2. Remove the four support clips.
3. Remove the adapter ring from the top of the unit.
a. Locate the two arrow marks on the adapter ring at the front
left corner of the unit (to left of control box) which indicates
the location for removal.
b. Pry that corner of the adapter ring from the top using a flat
head screwdriver.
c. Once the adapter ring is free on that corner, pry the other
three corners of the adapter ring until the adapter ring is free
from the unit top.
Figure 7. Removal Instructions
GGeenneerraall DDaattaa
