Trane BCI-I - Object Types

ACC-SVP01B-EN • BCI-I Integration Guide 19
BACnet Data Points and Configuration Property Definitions
Object Types
Table 2. Descriptions and configurations
Object
Type
Required Properties Read Properties Written
(a)
Optional Properties Read
Ability
to
Create
Ability to
Delete
Analog
Input
• Object_Identifier
•Object_Name
•Object_Type
• Present_Value
•Status_Flags
•Event_State
•Out_Of_Service
•Units
•Object_Name
•Description
•Out_Of_Service
• Present_Value
• Reliability
•Min_Pres_Value
•Max_Pres_Value
• COV_Increment
•Time_Delay
• Notification_Class
•High_Limit
•Low_Limit
•Deadband
•Limit_Enable
• Event_Enable
•Notify_Type
•Description
• Reliability
• Min_Pres_Value
•Max_Pres_Value
•COV_Increment
•Time_Delay
• Notification _Class
•High_Limit
•Low_Limit
•Deadband
•Limit_Enable
• Event_Enable
• Acked_Transitions
•Notify_Type
• Event_Time_Stamps
Yes Yes, only
user created
objects
Analog
Output
• Object_Identifier
•Object_Name
•Object_Type
• Present_Value
•Status_Flags
•Event_State
•Out_Of_Service
•Units
•Priority_Array
• Relinquish_Default
•Object_Name
•Description
•Out_Of_Service
• Present_Value
• Reliability
•Min_Pres_Value
•Max_Pres_Value
• Relinquish_Default
• COV_Increment
•Time_Delay
• Notification_Class
•High_Limit
•Low_Limit
•Deadband
•Limit_Enable
• Event_Enable
•Notify_Type
•Description
• Reliability
•Min_Pres-Value
•Max_Pres_Value
•COV_Increment
•Time_Delay
• Notification _Class
•High_Limit
•Low_Limit
•Deadband
•Limit_Enable
• Event_Enable
• Acked_Transitions
•Notify_Type
• Event_Time_Stamps
Yes Yes, only
user created
objects
Analog
Value
• Object_Identifier
•Object_Name
•Object_Type
• Present_Value
•Status_Flags
•Event_State
•Out_Of_Service
•Units
•Object_Name
•Description
•Out_Of_Service
• Present_Value
• Reliability
• Relinquish_Default
• COV_Increment
•Time_Delay
• Notification_Class
•High_Limit
•Low_Limit
•Deadband
•Limit_Enable
• Event_Enable
•Notify_Type
•Description
• Reliability
•Priority_Array
• Relinquish_Default
•COV_Increment
•Time_Delay
• Notification_Class
•High_Limit
•Low_Limit
•Deadband
•Limit_Enable
• Event_Enable
• Acked_Transitions
•Notify_Type
• Event_Time_Stamps
Yes Yes, only
user created
objects
Binary
Input
• Object_Identifier
•Object_Name
•Object_Type
• Present_Value
•Status_Flags
•Event_State
•Out_Of_Service
•Polarity
•Object_Name
•Description
•Out_Of_Service
•Inactive_Text
•Active_Text
• Present_Value
• Reliability
• Change_Of_State_Count
• Elapsed_Active_Time
•Time_Delay
• Notification_Class
•Alarm_Value
• Event_Enable
• Acked_Transitions
•Notify_Type
•Description
•Inactive_Text
•Active_Text
•Change_Of_State_Time
• Change_Of_State_Count
• Time_Of_State_Count_Reset
• Elapsed_Active_Time
• Time_Of_Active_Time_Reset
•Time_Delay
• Notification_Class
•Alarm_Value
• Event_Enable
• Acked_Transitions
•Notify_Type
• Event_Time_Stamps
• Reliability
Yes Yes, only
user created
objects
