32 ACC-SVP01B-EN • BCI-I Integration Guide
Object Data Points and Diagnostic Data Points
Binary Input, 32 Diagnostic: OA Temperature Sensor Fail Diagnostic: OA Temperature Sensor Fail
Binary Input, 33 Diagnostic: Mode Input Failure Diagnostic: Mode Input Failure
Binary Input, 34 Diagnostic: Occ Zone Cool Setpoint Fail Diagnostic: Occ Zone Cool Setpoint Fail
Binary Input, 35 Diagnostic: Occ Zone Heat Setpoint Fail Diagnostic: Occ Zone Heat Setpoint Fail
Binary Input, 36 Diagnostic: Supply Air Press Sensor Fail Diagnostic: Supply Air Press Sensor Fail
Binary Input, 37 Diagnostic: OA Humidity Sensor Failure Diagnostic: OA Humidity Sensor Failure
Binary Input, 38 Diagnostic: Emergency Stop Diagnostic: Emergency Stop
Binary Input, 39 Diagnostic: Supply Fan Failure Diagnostic: Supply Fan Failure
Binary Input, 40 Diagnostic: Exhaust/Return Fan Failure Diagnostic: Exhaust/Return Fan Failure
Binary Input, 41 Diagnostic: Lvg Evap Temp Sensor Fail - Ckt1 Diagnostic: Lvg Evap Temp Sensor Fail - Ckt1
Binary Input, 42 Diagnostic: Lvg Evap Temp Sensor Fail - Ckt2 Diagnostic: Lvg Evap Temp Sensor Fail - Ckt2
Binary Input, 43 Diagnostic: Low Pressure Ctl Open - Ckt1 Diagnostic: Low Pressure Ctl Open - Ckt1
Binary Input, 44 Diagnostic: Low Pressure Ctl Open - Ckt2 Diagnostic: Low Pressure Ctl Open - Ckt2
Binary Input, 45 Diagnostic: Cond Temp Sensor Fail - Ckt1 Diagnostic: Cond Temp Sensor Fail - Ckt1
Binary Input, 46 Diagnostic: Cond Temp Sensor Fail - Ckt2 Diagnostic: Cond Temp Sensor Fail - Ckt2
Binary Input, 47 Diagnostic: Compressor Trip - Ckt1 Diagnostic: Compressor Trip - Ckt1
Binary Input, 48 Diagnostic: Compressor Trip - Ckt2 Diagnostic: Compressor Trip - Ckt2
Binary Input, 49 Diagnostic: HEAT Aux Temp Sensor Fail Diagnostic: HEAT Aux Temp Sensor Fail
Binary Input, 50 Diagnostic: Low Air Temp Limit Trip Diagnostic: Low Air Temp Limit Trip
Binary Input, 51 Diagnostic: Heat Failure Diagnostic: Heat Failure
Binary Input, 52 Diagnostic: Unocc Zone Cool Stpnt Fail Diagnostic: Unocc Zone Cool Stpnt Fail
Binary Input, 53 Diagnostic: Unocc Zone Heat Stpnt Fail Diagnostic: Unocc Zone Heat Stpnt Fail
Binary Input, 54 Diagnostic: SA Duct Press Setpoint Fail Diagnostic: SA Duct Press Setpoint Fail
Binary Input, 55 Diagnostic: Space Pressure Setpoint Fail Diagnostic: Space Pressure Setpoint Fail
Binary Input, 56 Diagnostic: Space Pressure Sensor Fail Diagnostic: Space Pressure Sensor Fail
Binary Input, 57 Diagnostic: Return Air Temp Sensor Fail Diagnostic: Return Air Temp Sensor Fail
Binary Input, 58 (use Object
Identifier for RT or CSC)
Diagnostic: Return Air RH Sensor Failure Diagnostic: Return Air RH Sensor Failure
Binary Input, 58 (use Object
Identifier for FAU)
Diagnostic: Zone Humidity Sensor Failure Diagnostic: Zone Humidity Sensor Failure
Binary Input, 59 Diagnostic: Auto - SA High Press Limit Diagnostic: Auto - SA High Press Limit
Binary Input, 60 Diagnostic: Man - SA High Press Limit Diagnostic: Man - SA High Press Limit
Binary Input, 61 Diagnostic: SCM Communications Failure Diagnostic: SCM Communications Failure
Binary Input, 62 Diagnostic: MCM Communications Failure Diagnostic: MCM Communications Failure
Binary Input, 63 Diagnostic: HEAT Communications Failure Diagnostic: HEAT Communications Failure
Binary Input, 64 Diagnostic: ECEM Communications Failure Diagnostic: ECEM Communications Failure
Binary Input, 65 Diagnostic: GBAS 0-5 VDC Comm Failure Diagnostic: GBAS 0-5 VDC Comm Failure
Binary Input, 66 Diagnostic: BACnet Module Comm Fail Diagnostic: BACnet Module Comm Fail
Binary Input, 67 Diagnostic: BAS/Network Comm Fail Diagnostic: BAS/Network Comm Fail
Binary Input, 68 Diagnostic: NSB Panel Communication Fail Diagnostic: NSB Panel Communication Fail
Binary Input, 69 Diagnostic: RTM EEPROM Failure Diagnostic: RTM EEPROM Failure
Binary Input, 70 Diagnostic: Unit HI Communications Fail Diagnostic: Unit HI Communications Fail
Binary Input, 71 Diagnostic: VOM Communications Failure Diagnostic: VOM Communications Failure
Binary Input, 72 Diagnostic: Compressor Contact Fail-Ckt1 Diagnostic: Compressor Contact Fail-Ckt1
Binary Input, 73 Diagnostic: Compressor Contact Fail-Ckt2 Diagnostic: Compressor Contact Fail-Ckt2
Binary Input, 74 Diagnostic: SA Temp Cool Setpoint Fail Diagnostic: SA Temp Cool Setpoint Fail
Binary Input, 75 Diagnostic: SA Temp Heat Setpoint Fail Diagnostic: SA Temp Heat Setpoint Fail
Binary Input, 76 Diagnostic: Dirty Filter Diagnostic: Dirty Filter
Binary Input, 77 Diagnostic: NSB Zone Temp Sensor Fail Diagnostic: NSB Zone Temp Sensor Fail
Table 10. Diagnostics, Binary Input (continued)
Object Identifier
(a)
Object Name Description
