ACC-SVP01B-EN • BCI-I Integration Guide 37
Object Data Points and Diagnostic Data Points
Binary Output, 16 Humidification Command Command the operating state of the humidification system.
NC 3 HVAC-Advisory HVAC-Advisory
NC 1 HVAC-Critical HVAC-Critical
NC 4 HVAC-Information HVAC-Information
NC 2 HVAC-Service Required HVAC-Service Required
Analog Input, 25 Mixed Air Temperature The mixed air temperature value from a unit-mounted sensor.
Analog Input, 54 Morning Warmup Air Temperature Setpoint Active The air temperature setpoint used during morning warmup mode.
Analog Output, 4 Morning Warmup Setpoint BAS BAS supplied temperature setpoint used in morning warmup mode.
Multi-State Output, 7 Occupancy Mode Request BAS Command the unit into an occupancy mode.
Multi-State Input, 20 Occupancy Mode Status Indicates the current occupancy mode of the unit.
Analog Output, 29 Occupied Temperature Offset BAS Offset used to calculate setpoints in occupied mode.
Analog Input, 11 Outdoor Air Damper Position Status Indicates the unit outdoor air damper position.
Multi-State Input, 43 Outdoor Air Damper Status Indicates the operating state of the outdoor damper.
Analog Input, 22 Outdoor Air Dewpoint The outdoor air dewpoint value being utilized by the unit.
Analog Input, 23 Outdoor Air Enthalpy The outdoor air enthalpy value being utilized by the unit.
Analog Input, 34 Outdoor Air Flow Active Outdoor airflow utilized by the unit.
Analog Output, 17 Outdoor Air Flow BAS BAS supplied outdoor airflow sensor value.
Analog Input, 20 Outdoor Air Humidity Active The outdoor air humidity value used for unit control.
Analog Output, 15 Outdoor Air Humidity BAS BAS supplied outdoor air humidity sensor value.
Analog Input, 21 Outdoor Air Humidity Local The outdoor air humidity value from a unit-mounted sensor.
Analog Input, 57 Outdoor Air Minimum Flow Setpoint Active The minimum outdoor airflow setpoint being utilized by the unit.
Analog Output, 16 Outdoor Air Minimum Flow Setpoint BAS BAS supplied minimum outdoor airflow setpoint.
Analog Input, 18 Outdoor Air Temperature Active The outdoor air temperature currently used for unit control.
Analog Output, 14 Outdoor Air Temperature BAS BAS supplied outdoor air temperature sensor value.
Analog Input, 19 Outdoor Air Temperature Local The outdoor air temperature value from a unit-mounted sensor.
Multi-State Input, 34 Prefilter Status Indicates the prefilter media state.
Analog Input, 82 Preheat Type Describes the heating type installed in the unit.
Multi-State Input, 35 Primary Filter Status Indicates the primary filter media state.
Analog Input, 5 Reheat Capacity Status Indicates the unit reheat heating capacity being utilized.
Analog Input, 83 Reheat Type Describes the reheat type installed in the unit.
Analog Input, 26 Return Air Temperature The return air temperature value from a unit-mounted sensor.
Analog Input, 30 Return Fan Air Pressure Return fan air pressure value measured by a unit-mounted sensor.
Multi-State Input, 40 Return Fan Proving Status Indicates the current state of the return fan.
Analog Input, 10 Return Fan Speed Command Indicates the unit commanded return fan speed.
Multi-State Input, 42 Return Fan Status Indicates the state of the return fan.
Binary Input, 11 Service Test Mode Status Indicates if the unit is in service test mode.
Analog Output, 11 Space Air Temperature BAS BAS supplied space air temperature sensor value.
Analog Input, 87 Space Air Temperature Local The space air temperature measured by a unit-mounted sensor.
Analog Input, 50 Space Air Temperature Setpoint Active Space temperature setpoint value being used for unit control.
Analog Output, 2 Space Air Temperature Setpoint BAS Base value to calculate setpoints in occupied and standby modes.
Analog Input, 32 Space CO
2
Concentration Active Space CO
2
concentration being used for unit control.
Analog Output, 18 Space CO
2
Concentration BAS BAS supplied space CO
2
sensor value.
Analog Input, 84 Space CO2 High Limit Setpoint Indicates the high limit space CO
2
setpoint for ventilation.
Analog Input, 85 Space CO2 Low Limit Setpoint Indicates the low limit space CO
2
setpoint for ventilation.
Analog Output, 21 Space Dehumidification Setpoint BAS BAS supplied space dehumidification setpoint value.
Analog Input, 17 Space Enthalpy The space enthalpy value from a unit-mounted control.
Table 11. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) (continued)
Object Identifier
(a)
Object Name Description
