7.6.4 Customer plant sketch without primary pump on the condenser side of
CGWF SE / CGWF HE / CXWF units
Figure 26
IMPORTANT: the steel mesh strainer in the customer plant is obligatory in order
to keep the warranty, the flow switch is optional
P1 Primary Pump
P2 Secondary Pump
ST Temperature Probe
FL Flow Switch
SC Drainage
SF Vent Valve
ET Expansion Vessel
GR Filling group
F Steel Mesh Strainer
VR Check Valve
SV Safety Valve
RB Interception valve
HOT WATER
TANK
CUSTOMER PLANT
FANCOIL
AIR CONDITIONING
WATER PUMP
