Start-Up
WSHP-SVX01L-EN 97
EXVF030
(60 Hz)
35 5.5 87-101 266-337 6-7 20-25
35 7.0 89-103 267-340 4-6 20-26
45 5.5 137-158 164-214 12-15 22-28 102-118 284-359 7-8 23-29
45 7.0 137-157 158-206 9-12 22-27 105-121 286-362 5-7 23-30
55 5.5 138-159 192-250 12-15 21-27 119-137 299-379 8-10 26-33
55 7.0 138-159 185-241 9-12 21-27 122-141 302-382 6-8 27-34
68 5.5 140-161 231-301 11-15 20-26 143-165 328-413 9-12 30-38
68 7.0 140-161 223-291 9-11 21-26 148-170 332-419 7-9 30-39
75 5.5 141-162 257-334 11-14 20-25 158-182 341-430 10-13 32-40
75 7.0 141-162 249-323 9-11 20-26 164-188 346-436 8-10 32-41
86 5.5 143-164 300-388 11-14 19-25 183-211 364-460 11-14 34-43
86 7.0 142-164 291-377 9-11 20-25 190-219 368-465 9-11 34-44
95 5.5 144-165 340-440 11-14 19-24
95 7.0 144-165 331-428 9-11 19-24
EXVF036
(60 Hz)
35 6.6 88-101 292-368 6-7 19-24
35 8.4 89-103 293-369 5-6 19-24
45 6.6 133-153 169-218 12-15 20-26 103-118 310-390 7-8 23-29
45 8.4 132-152 162-210 9-12 21-26 105-121 311-392 5-7 23-29
55 6.6 134-154 197-254 12-15 20-26 119-137 327-412 8-10 26-33
55 8.4 134-154 190-245 9-12 20-26 122-141 330-415 6-8 26-34
68 6.6 136-156 236-304 12-15 20-25 144-166 362-454 9-12 30-39
68 8.4 136-156 228-295 9-12 20-25 148-171 365-457 7-9 31-39
75 6.6 137-158 261-336 11-14 20-25 159-183 378-474 10-13 33-42
75 8.4 137-158 253-326 9-11 20-25 164-189 382-479 8-10 33-42
86 6.6 139-160 303-390 11-14 19-24 184-212 403-506 11-15 35-45
86 8.4 139-160 295-379 9-11 19-24 191-219 409-514 9-12 36-45
95 6.6 141-162 342-439 11-14 19-24
95 8.4 141-162 333-428 9-11 19-24
EXVF042
(60 Hz)
35 7.8 84-97 285-358 5-7 19-24
35 9.8 86-99 286-359 4-6 19-25
45 7.8 134-155 160-210 12-15 21-27 99-114 300-377 6-8 22-28
45 9.8 134-154 153-202 10-12 21-27 101-116 302-379 5-7 22-29
55 7.8 135-156 189-247 12-15 21-27 115-132 315-396 7-9 25-32
55 9.8 135-156 182-238 9-12 21-27 118-136 319-400 6-8 26-32
68 7.8 137-158 229-299 12-15 21-26 139-160 352-438 9-11 29-37
68 9.8 137-158 221-289 9-12 21-26 143-165 354-442 7-9 30-38
75 7.8 138-159 255-332 12-15 20-26 154-177 365-456 10-12 32-40
75 9.8 138-159 247-322 9-12 20-26 158-182 369-460 8-10 32-41
86 7.8 140-161 299-389 11-15 19-25 179-205 388-485 11-14 34-43
86 9.8 140-161 291-379 9-12 19-25 184-212 392-490 9-11 34-44
95 7.8 142-163 341-442 11-14 19-24
95 9.8 142-163 332-430 9-11 19-24
Table 50. Operating pressures in cooling/heating for EX units (continued)
Operating Data
Cooling Heating
Model
Entering
water
temp (ºF)
Water
flow
(GPM)
Suction
pressure
(psig)
Discharge
pressure
(psig)
Water
temp rise
(ºF)
Air temp
drop
(ºF DB)
Suction
pressure
(psig)
Discharge
pressure
(psig)
Water
Temp drop
(ºF)
Air temp
rise
(ºF DB)
