Trane EXHF - Page 98

Start-Up
98 WSHP-SVX01L-EN
EXVF048
(60 Hz)
35 8.8 87-101 285-359 6-7 20-25
35 11.2 90-103 287-362 5-6 20-26
45 8.8 135-156 172-222 12-15 21-27 103-118 300-378 7-8 23-29
45 11.2 135-155 165-214 9-12 22-28 105-121 303-382 5-7 23-30
55 8.8 136-157 201-259 12-15 21-27 120-138 316-398 8-10 26-33
55 11.2 136-157 193-249 9-12 21-27 123-142 320-403 6-8 27-34
68 8.8 138-159 243-313 12-15 20-26 144-166 348-437 9-12 30-38
68 11.2 138-159 235-303 9-12 21-26 149-171 352-442 7-9 31-39
75 8.8 139-160 269-345 11-15 20-25 159-183 363-455 10-13 32-40
75 11.2 139-160 260-334 9-11 20-26 165-189 367-461 8-10 32-41
86 8.8 141-162 310-399 11-14 19-25 184-212 386-485 11-14 33-42
86 11.2 141-162 301-387 9-11 19-25 191-220 392-493 9-12 34-43
95 8.8 143-164 349-448 11-14 19-24
95 11.2 143-164 340-437 9-11 19-24
EXVF060
(60 Hz)
35 11.6 89-102 300-377 6-7 21-27
35 14.0 90-104 301-379 5-6 21-27
45 11.6 132-152 169-219 12-15 21-27 104-120 324-406 7-9 24-31
45 14.0 132-152 164-212 10-13 21-26 106-122 325-407 6-7 24-31
55 11.6 133-153 197-254 12-15 20-26 121-139 343-430 8-10 27-35
55 14.0 133-153 192-247 10-12 21-26 124-142 344-432 7-8 28-35
68 11.6 135-156 235-303 12-15 20-26 146-168 377-472 9-12 31-40
68 14.0 135-156 229-296 10-12 20-26 150-172 380-476 8-10 32-40
75 11.6 136-157 260-335 11-14 20-25 161-185 394-493 10-13 33-42
75 14.0 136-157 253-326 9-12 20-26 165-190 398-499 9-11 34-43
86 11.6 138-159 302-388 11-14 20-25 186-214 424-532 12-15 36-45
86 14.0 138-159 295-379 9-12 20-25 192-221 429-538 10-12 36-46
95 11.6 140-161 339-436 11-14 19-24
95 14.0 140-161 332-427 9-12 19-25
EXVF070
(60 Hz)
35 12.32 86-100 294-371 6-7 20-26
35 15.4 88-102 296-373 5-6 21-26
45 12.32 131-150 166-216 12-15 21-27 101-117 320-401 7-9 23-29
45 15.4 131-150 160-208 10-12 21-27 104-119 322-404 6-7 24-30
55 12.32 131-151 194-252 12-15 21-27 118-136 338-424 8-10 26-33
55 15.4 131-151 188-243 10-12 21-27 121-139 340-427 6-8 27-34
68 12.32 133-153 235-303 12-15 20-26 142-164 374-467 9-12 31-39
68 15.4 133-153 228-294 9-12 21-26 146-168 376-470 8-10 31-40
75 12.32 134-154 259-335 12-15 20-26 157-180 389-487 10-13 33-42
75 15.4 134-154 252-325 9-12 20-26 162-186 393-492 8-11 34-43
86 12.32 136-156 297-384 11-15 20-25 181-209 417-523 12-15 37-47
86 15.4 136-156 289-374 9-12 20-25 188-216 422-529 9-12 38-48
95 12.32 137-158 335-432 11-14 19-25
95 15.4 137-158 327-422 9-12 19-25
Table 50. Operating pressures in cooling/heating for EX units (continued)
Operating Data
Cooling Heating
Model
Entering
water
temp (ºF)
Water
flow
(GPM)
Suction
pressure
(psig)
Discharge
pressure
(psig)
Water
temp rise
(ºF)
Air temp
drop
(ºF DB)
Suction
pressure
(psig)
Discharge
pressure
(psig)
Water
Temp drop
(ºF)
Air temp
rise
(ºF DB)
