WSHP-PRC004-EN26
GECA 006 –
Heating – I-P
Performance
Data
Tabulated performance data is tabulated for heating at 68 F [20 C] DB entering air at ARI-ISO 13256-1 rated CFM.
Multipliers must be used to correct performance at conditions other than those tabulated. Data shown in
BOLD
type is performance and
multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 1.8 MINIMUM CFM: 160 RATED CFM: 250 MAXIMUM CFM: 250
Table PD-2 – 006 Heating Performance
EWT Htg Cap Absorb Power LWT Ft. ISO Cap ISO Pwr ISO
F GPM Mbtuh Mbtuh kW COP F Hd CFM Mbtuh kW COP
1.2 4.9 3.8 0.56 2.6 15.3 1.5 250 4.9 0.56 2.6
1.4 5.1 4.0 0.56 2.7 17.5 2.1 250 5.1 0.56 2.6
1.6 5.2 4.2 0.56 2.7 18.7 2.5 250 5.2 0.57 2.7
25 1.7 5.3 4.3 0.56 2.7 19.7 2.9 250 5.3 0.57 2.7
1.8 5.3 4.3 0.57 2.8 20.1 3.1 250 5.3 0.57 2.7
1.9 5.4 4.4 0.57 2.8 20.5 3.3 250 5.4 0.57 2.8
2.1 5.5 4.5 0.57 2.8 21.1 3.8 250 5.5 0.57 2.8
1.2 5.7 4.7 0.57 2.9 24.4 1.5 250 5.7 0.57 2.9
1.4 5.9 4.9 0.58 3.0 26.6 2.1 250 5.9 0.58 3.0
1.6 6.0 5.0 0.58 3.1 27.8 2.5 250 6.0 0.58 3.0
35 1.7 6.1 5.1 0.58 3.1 28.8 2.9 250 6.1 0.58 3.1
1.8 6.2 5.2 0.58 3.1 29.2 3.1 250 6.2 0.58 3.1
1.9 6.2 5.2 0.58 3.1 29.6 3.3 250 6.2 0.59 3.1
2.1 6.3 5.3 0.58 3.2 30.2 3.8 250 6.3 0.59 3.1
1.2 6.6 5.6 0.59 3.3 33.4 1.5 250 6.6 0.59 3.3
1.4 6.8 5.8 0.59 3.4 35.6 2.1 250 6.8 0.59 3.3
1.6 6.9 5.9 0.59 3.4 36.8 2.5 250 6.9 0.60 3.4
45 1.7 7.0 6.1 0.60 3.4 37.8 2.9 250 7.0 0.60 3.4
1.8 7.0 6.1 0.60 3.4 38.3 3.1 250 7.0 0.60 3.4
1.9 7.1 6.2 0.60 3.5 38.6 3.3 250 7.1 0.60 3.4
2.1 7.2 6.3 0.60 3.5 39.2 3.8 250 7.2 0.61 3.5
1.2 7.5 6.6 0.61 3.6 42.4 1.5 250 7.5 0.61 3.6
1.4 7.6 6.8 0.61 3.7 44.6 2.1 250 7.6 0.61 3.7
1.6 7.8 6.9 0.61 3.7 45.8 2.5 250 7.8 0.62 3.7
55 1.7 7.9 7.0 0.62 3.7 46.8 2.9 250 7.9 0.62 3.7
1.8 7.9 7.0 0.62 3.8 47.3 3.1 250 7.9 0.62 3.7
1.9 7.9 7.1 0.62 3.8 47.6 3.3 250 7.9 0.62 3.7
2.1 8.0 7.2 0.62 3.8 48.2 3.8 250 8.0 0.62 3.8
1.2 8.7 7.9 0.63 4.0 54.4 1.5 250 8.7 0.64 4.0
1.4 8.8 8.1 0.64 4.1 56.6 2.1 250 8.8 0.64 4.1
1.6 8.9 8.2 0.64 4.1 57.7 2.5 250 8.9 0.64 4.1
68 1.7 9.0 8.3 0.64 4.1 58.5 2.9 250 9.0 0.65 4.1
1.8 9.1 8.3 0.64 4.1 58.9 3.1 250 9.1 0.65 4.1
1.9 9.1 8.4 0.64 4.1 59.3 3.3 250 9.1 0.65 4.1
2.1 9.2 8.4 0.65 4.2 59.9 3.8 250 9.2 0.65 4.1
1.2 9.5 8.7 0.65 4.3 62.1 1.5 250 9.5 0.65 4.2
1.4 9.6 8.9 0.66 4.3 64.3 2.0 250 9.6 0.66 4.3
1.6 9.8 9.0 0.66 4.3 65.5 2.4 250 9.8 0.66 4.3
77 1.7 9.9 9.2 0.66 4.4 66.5 2.9 250 9.9 0.66 4.3
1.8 9.9 9.2 0.66 4.4 66.9 3.1 250 9.9 0.67 4.4
1.9 10.0 9.3 0.66 4.4 67.3 3.3 250 10.0 0.67 4.4
2.1 10.0 9.4 0.67 4.4 68.0 3.8 250 10.0 0.67 4.4
1.2 10.2 9.6 0.67 4.5 69.5 1.5 250 10.2 0.67 4.5
1.4 10.4 9.8 0.68 4.5 72.1 2.0 250 10.4 0.68 4.5
1.6 10.6 9.9 0.68 4.6 73.3 2.4 250 10.6 0.68 4.5
86 1.7 10.7 10.1 0.68 4.6 74.4 2.9 250 10.7 0.69 4.6
1.8 10.7 10.1 0.68 4.6 74.9 3.1 250 10.7 0.69 4.6
1.9 10.8 10.2 0.69 4.6 75.3 3.3 250 10.8 0.69 4.6
2.1 10.9 10.3 0.69 4.6 76.0 3.8 250 10.9 0.69 4.6
Table 3 – Fan Correction Factors – Model GECA 006
Entering Cooling Sensible Cooling Input Heating Heating Input
CFM Capacity Capacity Watts Capacity Watts
200 0.963 0.920 0.998 0.957 1.077
250 1.000 1.000 1.000 1.000 1.000
