27
WSHP-PRC004-EN
Performance
Data
GECA 006 –
Heating – SI
Tabulated performance data is tabulated for heating at 68 F [20 C] DB entering air at ARI-ISO 13256-1 rated CFM.
Multipliers must be used to correct performance at conditions other than those tabulated. Data shown in
BOLD
type is performance and
multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED L/S: .11 MINIMUM CMH: 272 RATED CMH: 425 MAXIMUM CMH: 425
Table PD-2 – 006 Heating Performance
EWT Htg Cap Absorb Power LWT KPa ISO Cap ISO Pwr ISO
C L/S kW kW kW COP C of Water CMH kW kW COP
0.08 1.44 1.11 0.56 2.6 -9.3 4.5 425 1.44 0.56 2.6
0.09 1.49 1.17 0.56 2.7 -8.1 6.3 425 1.49 0.56 2.6
0.10 1.52 1.23 0.56 2.7 -7.4 7.5 425 1.52 0.57 2.7
-4 0.11 1.55 1.26 0.56 2.7 -6.8 8.7 425 1.55 0.57 2.7
0.11 1.55 1.26 0.57 2.8 -6.6 9.3 425 1.55 0.57 2.7
0.12 1.58 1.29 0.57 2.8 -6.4 9.9 425 1.58 0.57 2.8
0.13 1.61 1.32 0.57 2.8 -6.1 11.4 425 1.61 0.57 2.8
0.08 1.67 1.38 0.57 2.9 -4.2 4.5 425 1.67 0.57 2.9
0.09 1.73 1.44 0.58 3.0 -3.0 6.3 425 1.73 0.58 3.0
0.10 1.76 1.47 0.58 3.1 -2.3 7.5 425 1.76 0.58 3.0
2 0.11 1.79 1.49 0.58 3.1 -1.8 8.7 425 1.79 0.58 3.1
0.11 1.82 1.52 0.58 3.1 -1.6 9.3 425 1.82 0.58 3.1
0.12 1.82 1.52 0.58 3.1 -1.3 9.9 425 1.82 0.59 3.1
0.13 1.85 1.55 0.58 3.2 -1.0 11.4 425 1.85 0.59 3.1
0.08 1.93 1.64 0.59 3.3 0.8 4.5 425 1.93 0.59 3.3
0.09 1.99 1.70 0.59 3.4 2.0 6.3 425 1.99 0.59 3.3
0.10 2.02 1.73 0.59 3.4 2.7 7.5 425 2.02 0.60 3.4
7 0.11 2.05 1.79 0.60 3.4 3.2 8.7 425 2.05 0.60 3.4
0.11 2.05 1.79 0.60 3.4 3.5 9.3 425 2.05 0.60 3.4
0.12 2.08 1.82 0.60 3.5 3.7 9.9 425 2.08 0.60 3.4
0.13 2.11 1.85 0.60 3.5 4.0 11.4 425 2.11 0.61 3.5
0.08 2.20 1.93 0.61 3.6 5.8 4.5 425 2.20 0.61 3.6
0.09 2.23 1.99 0.61 3.7 7.0 6.3 425 2.23 0.61 3.7
0.10 2.29 2.02 0.61 3.7 7.7 7.5 425 2.29 0.62 3.7
13 0.11 2.31 2.05 0.62 3.7 8.2 8.7 425 2.31 0.62 3.7
0.11 2.31 2.05 0.62 3.8 8.5 9.3 425 2.31 0.62 3.7
0.12 2.31 2.08 0.62 3.8 8.7 9.9 425 2.31 0.62 3.7
0.13 2.34 2.11 0.62 3.8 9.0 11.4 425 2.34 0.62 3.8
0.08 2.55 2.31 0.63 4.0 12.4 4.5 425 2.55 0.64 4.0
0.09 2.58 2.37 0.64 4.1 13.7 6.3 425 2.58 0.64 4.1
0.10 2.61 2.40 0.64 4.1 14.3 7.5 425 2.61 0.64 4.1
20 0.11 2.64 2.43 0.64 4.1 14.7 8.7 425 2.64 0.65 4.1
0.11 2.67 2.43 0.64 4.1 14.9 9.3 425 2.67 0.65 4.1
0.12 2.67 2.46 0.64 4.1 15.2 9.9 425 2.67 0.65 4.1
0.13 2.70 2.46 0.65 4.2 15.5 11.4 425 2.70 0.65 4.1
0.08 2.78 2.55 0.65 4.3 16.7 4.5 425 2.78 0.65 4.2
0.09 2.81 2.61 0.66 4.3 17.9 6.0 425 2.81 0.66 4.3
0.10 2.87 2.64 0.66 4.3 18.6 7.2 425 2.87 0.66 4.3
25 0.11 2.90 2.70 0.66 4.4 19.2 8.7 425 2.90 0.66 4.3
0.11 2.90 2.70 0.66 4.4 19.4 9.3 425 2.90 0.67 4.4
0.12 2.93 2.72 0.66 4.4 19.6 9.9 425 2.93 0.67 4.4
0.13 2.93 2.75 0.67 4.4 20.0 11.4 425 2.93 0.67 4.4
0.08 2.99 2.81 0.67 4.5 20.8 4.5 425 2.99 0.67 4.5
0.09 3.05 2.87 0.68 4.5 22.3 6.0 425 3.05 0.68 4.5
0.10 3.11 2.90 0.68 4.6 22.9 7.2 425 3.11 0.68 4.5
30 0.11 3.14 2.96 0.68 4.6 23.6 8.7 425 3.14 0.69 4.6
0.11 3.14 2.96 0.68 4.6 23.8 9.3 425 3.14 0.69 4.6
0.12 3.16 2.99 0.69 4.6 24.1 9.9 425 3.16 0.69 4.6
0.13 3.19 3.02 0.69 4.6 24.4 11.4 425 3.19 0.69 4.6
Table 3 – Fan Correction Factors – Model GECA 006
Entering Cooling Sensible Cooling Input Heating Heating Input
CMH Capacity Capacity Watts Capacity Watts
340 0.963 0.920 0.998 0.957 1.077
425 1.000 1.000 1.000 1.000 1.000
