WSHP-PRC004-EN28
GECA 009 –
Cooling – I-P
Performance
Data
Tabulated performance data is for cooling at 80.6 F [27 C] DB/66.2 F [19 C] WB entering air at ARI-ISO 13256-1 rated CFM.
Sensible multipliers vs. entering dry bulb are given at ARI-ISO 13256-1 rating CFM. Multipliers must be used to correct performance at conditions
other than those tabulated. Data shown is
BOLD
type is performance and multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 2.3 MINIMUM CFM: 240 RATED CFM: 300 MAXIMUM CFM: 300
Table PD-4 – 009 Cooling Performance
EWT Total Sens Power Reject LWT Ft. ISO Cap ISO Pwr ISO
F GPM Mbtuh Mbtuh SHR kW EER Mbtuh F Hd CFM Mbtuh kW EER
1.5 12.0 8.8 0.73 0.60 20.1 14.3 63.4 3.0 333 12.0 0.60 20.0
1.8 12.1 8.8 0.73 0.60 20.2 14.3 60.0 4.1 333 12.1 0.60 20.1
2.1 12.1 8.8 0.73 0.58 20.7 14.3 58.2 5.0 333 12.1 0.59 20.5
45 2.3 12.1 8.8 0.73 0.57 21.3 14.3 56.9 6.0 333 12.1 0.58 21.0
2.4 12.1 8.8 0.73 0.57 21.4 14.3 56.5 6.3 333 12.1 0.58 21.0
2.6 12.2 8.8 0.73 0.56 21.6 14.3 55.7 7.1 333 12.2 0.58 21.1
2.7 12.2 8.8 0.72 0.56 21.7 14.3 55.1 7.8 333 12.2 0.57 21.2
2.9 12.2 8.8 0.72 0.56 21.8 14.3 54.5 8.6 333 12.2 0.57 21.2
1.5 11.8 8.7 0.73 0.69 17.3 14.2 73.4 2.9 333 11.8 0.69 17.2
1.8 11.9 8.7 0.73 0.67 17.8 14.3 70.0 4.1 333 11.9 0.67 17.6
2.1 11.9 8.7 0.73 0.66 18.1 14.3 68.2 5.0 333 11.9 0.66 17.9
55 2.3 11.9 8.7 0.73 0.65 18.3 14.3 66.8 6.0 333 11.9 0.66 18.1
2.4 11.9 8.7 0.73 0.65 18.4 14.3 66.4 6.3 333 11.9 0.66 18.1
2.6 11.9 8.7 0.73 0.64 18.5 14.3 65.7 7.1 333 11.9 0.66 18.2
2.7 11.9 8.7 0.73 0.64 18.6 14.3 65.0 7.8 333 11.9 0.65 18.3
2.9 11.9 8.7 0.73 0.64 18.7 14.3 64.5 8.6 333 11.9 0.65 18.3
1.5 11.4 8.5 0.74 0.80 14.3 14.0 86.2 2.9 333 11.4 0.80 14.3
1.8 11.5 8.5 0.74 0.78 14.8 14.1 82.9 4.1 333 11.5 0.78 14.7
2.1 11.5 8.5 0.74 0.77 15.0 14.1 81.1 5.0 333 11.5 0.77 14.9
68 2.3 11.5 8.5 0.74 0.76 15.2 14.1 79.7 6.0 333 11.5 0.77 15.0
2.4 11.5 8.6 0.74 0.76 15.3 14.1 79.3 6.3 333 11.5 0.77 15.1
2.6 11.6 8.6 0.74 0.75 15.4 14.1 78.6 7.0 333 11.6 0.76 15.2
2.7 11.6 8.6 0.74 0.75 15.5 14.1 78.0 7.8 333 11.6 0.76 15.2
2.9 11.6 8.6 0.74 0.74 15.6 14.1 77.4 8.6 333 11.6 0.76 15.2
1.5 11.1 8.4 0.75 0.88 12.7 13.8 95.0 2.9 333 11.1 0.88 12.6
1.8 11.2 8.4 0.75 0.86 13.0 13.9 91.7 4.0 333 11.2 0.86 13.0
2.1 11.2 8.4 0.75 0.84 13.3 13.9 90.0 5.0 333 11.2 0.85 13.2
77 2.3 11.2 8.4 0.75 0.84 13.4 13.9 88.6 6.0 333 11.2 0.84 13.3
2.4 11.2 8.4 0.75 0.83 13.5 13.9 88.2 6.3 333 11.2 0.84 13.3
2.6 11.3 8.4 0.75 0.83 13.6 13.9 87.5 7.0 333 11.3 0.84 13.4
2.7 11.3 8.4 0.75 0.82 13.7 13.9 86.9 7.8 333 11.3 0.84 13.5
2.9 11.3 8.4 0.75 0.82 13.7 13.9 86.3 8.5 333 11.3 0.84 13.5
1.5 10.7 8.2 0.76 0.96 11.2 13.6 103.7 2.9 333 10.7 0.96 11.2
1.8 10.8 8.2 0.76 0.94 11.5 13.7 100.5 4.0 333 10.8 0.94 11.5
2.1 10.8 8.2 0.76 0.92 11.7 13.7 98.8 5.0 333 10.8 0.93 11.7
86 2.3 10.9 8.3 0.76 0.91 11.9 13.7 97.4 6.0 333 10.9 0.92 11.8
2.4 10.9 8.3 0.76 0.91 11.9 13.7 97.0 6.3 333 10.9 0.92 11.8
2.6 10.9 8.3 0.76 0.91 12.0 13.7 96.3 7.0 333 10.9 0.92 11.9
2.7 10.9 8.3 0.76 0.90 12.1 13.7 95.7 7.8 333 10.9 0.92 11.9
2.9 10.9 8.3 0.76 0.90 12.2 13.7 95.2 8.5 333 10.9 0.91 12.0
1.5 10.3 8.0 0.78 1.04 9.9 13.4 112.4 2.6 333 10.3 1.04 9.9
1.8 10.4 8.1 0.77 1.02 10.2 13.4 109.3 3.6 333 10.4 1.02 10.2
2.1 10.5 8.1 0.77 1.01 10.4 13.4 107.6 4.4 333 10.5 1.01 10.3
95 2.3 10.5 8.1 0.77 1.00 10.5 13.4 106.3 5.3 333 10.5 1.00 10.5
2.4 10.5 8.1 0.77 0.99 10.6 13.4 105.9 5.6 333 10.5 1.00 10.5
2.6 10.5 8.1 0.77 0.99 10.7 13.5 105.2 6.2 333 10.5 1.00 10.6
2.7 10.5 8.1 0.77 0.98 10.7 13.5 104.6 6.9 333 10.5 0.99 10.6
2.9 10.6 8.1 0.77 0.98 10.8 13.5 104.0 7.6 333 10.6 0.99 10.6
1.5 9.9 7.8 0.79 1.13 8.8 13.0 122.2 2.5 333 9.9 1.13 8.7
1.8 9.9 7.9 0.79 1.11 9.0 13.1 119.0 3.6 333 9.9 1.11 8.9
2.1 10.0 7.9 0.79 1.10 9.1 13.1 117.3 4.4 333 10.0 1.10 9.1
105 2.3 10.0 7.9 0.79 1.09 9.2 13.1 116.0 5.3 333 10.0 1.09 9.2
2.4 10.0 7.9 0.79 1.08 9.3 13.1 115.6 5.6 333 10.0 1.09 9.2
2.6 10.1 7.9 0.79 1.08 9.3 13.1 115.0 6.2 333 10.1 1.09 9.2
2.7 10.1 7.9 0.79 1.07 9.4 13.1 114.4 6.8 333 10.1 1.09 9.3
2.9 10.1 7.9 0.79 1.07 9.4 13.2 113.8 7.5 333 10.1 1.08 9.3
1.5 9.4 7.6 0.81 1.22 7.7 12.7 132.0 2.5 333 9.4 1.23 7.7
1.8 9.4 7.6 0.81 1.20 7.9 12.7 129.1 3.5 333 9.4 1.21 7.8
2.1 9.5 7.6 0.80 1.19 8.0 12.7 127.3 4.3 333 9.5 1.20 7.9
115 2.3 9.5 7.7 0.80 1.18 8.1 12.7 125.8 5.2 333 9.5 1.19 8.0
2.4 9.5 7.7 0.80 1.18 8.1 12.7 125.4 5.5 333 9.5 1.18 8.0
2.6 9.5 7.7 0.80 1.17 8.2 12.8 124.6 6.2 333 9.5 1.18 8.1
2.7 9.6 7.7 0.80 1.17 8.2 12.8 124.1 6.8 333 9.6 1.18 8.1
2.9 9.6 7.7 0.80 1.16 8.2 12.8 123.7 7.5 333 9.6 1.18 8.1
1.5 9.1 7.4 0.82 1.27 7.2 12.5 136.8 2.5 333 9.1 1.27 7.2
1.8 9.2 7.5 0.82 1.25 7.3 12.5 133.9 3.5 333 9.2 1.25 7.3
2.1 9.2 7.5 0.81 1.24 7.4 12.5 132.1 4.3 333 9.2 1.24 7.4
120 2.3 9.2 7.5 0.81 1.23 7.5 12.5 130.6 5.2 333 9.2 1.23 7.5
2.4 9.3 7.5 0.81 1.22 7.6 12.5 130.2 5.5 333 9.3 1.23 7.5
2.6 9.3 7.5 0.81 1.22 7.6 12.5 129.5 6.1 333 9.3 1.23 7.5
2.7 9.3 7.5 0.81 1.22 7.6 12.6 128.9 6.8 333 9.3 1.23 7.6
2.9 9.3 7.5 0.81 1.21 7.7 12.6 128.5 7.5 333 9.3 1.23 7.6
