29
WSHP-PRC004-EN
GECA 009 –
Cooling – SI
Performance
Data
Tabulated performance data is for cooling at 80.6 F [27 C] DB/66.2 F [19 C] WB entering air at ARI-ISO 13256-1 rated CFM.
Sensible multipliers vs. entering dry bulb are given at ARI-ISO 13256-1 rating CFM. Multipliers must be used to correct performance at conditions
other than those tabulated. Data shown is
BOLD
type is performance and multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED L/S: .14 MINIMUM CMH: 408 RATED CMH: 509 MAXIMUM CMH: 509
Table PD-4 – 009 Cooling Performance
EWT Total Sens Power Reject LWT KPa of ISO Cap ISO Pwr ISO
C L/S kW kW SHR kW EER kW C Water CMH kW kW EER
0.09 3.52 2.58 0.73 0.60 20.1 4.19 17.4 9.0 565 3.52 0.60 20.0
0.11 3.55 2.58 0.73 0.60 20.2 4.19 15.6 12.3 565 3.55 0.60 20.1
0.13 3.55 2.58 0.73 0.58 20.7 4.19 14.6 15.0 565 3.55 0.59 20.5
7.2 0.15 3.55 2.58 0.73 0.57 21.3 4.19 13.8 18.0 565 3.55 0.58 21.0
0.15 3.55 2.58 0.73 0.57 21.4 4.19 13.6 18.9 565 3.55 0.58 21.0
0.16 3.57 2.58 0.73 0.56 21.6 4.19 13.2 21.3 565 3.57 0.58 21.1
0.17 3.57 2.58 0.72 0.56 21.7 4.19 12.8 23.4 565 3.57 0.57 21.2
0.18 3.57 2.58 0.72 0.56 21.8 4.19 12.5 25.8 565 3.57 0.57 21.2
0.09 3.46 2.55 0.73 0.69 17.3 4.16 23.0 8.7 565 3.46 0.69 17.2
0.11 3.49 2.55 0.73 0.67 17.8 4.19 21.1 12.3 565 3.49 0.67 17.6
0.13 3.49 2.55 0.73 0.66 18.1 4.19 20.1 15.0 565 3.49 0.66 17.9
12.8 0.15 3.49 2.55 0.73 0.65 18.3 4.19 19.3 18.0 565 3.49 0.66 18.1
0.15 3.49 2.55 0.73 0.65 18.4 4.19 19.1 18.9 565 3.49 0.66 18.1
0.16 3.49 2.55 0.73 0.64 18.5 4.19 18.7 21.3 565 3.49 0.66 18.2
0.17 3.49 2.55 0.73 0.64 18.6 4.19 18.3 23.4 565 3.49 0.65 18.3
0.18 3.49 2.55 0.73 0.64 18.7 4.19 18.1 25.8 565 3.49 0.65 18.3
0.09 3.34 2.49 0.74 0.80 14.3 4.10 30.1 8.7 565 3.34 0.80 14.3
0.11 3.37 2.49 0.74 0.78 14.8 4.13 28.3 12.3 565 3.37 0.78 14.7
0.13 3.37 2.49 0.74 0.77 15.0 4.13 27.3 15.0 565 3.37 0.77 14.9
20.0 0.15 3.37 2.49 0.74 0.76 15.2 4.13 26.5 18.0 565 3.37 0.77 15.0
0.15 3.37 2.52 0.74 0.76 15.3 4.13 26.3 18.9 565 3.37 0.77 15.1
0.16 3.40 2.52 0.74 0.75 15.4 4.13 25.9 21.0 565 3.40 0.76 15.2
0.17 3.40 2.52 0.74 0.75 15.5 4.13 25.6 23.4 565 3.40 0.76 15.2
0.18 3.40 2.52 0.74 0.74 15.6 4.13 25.2 25.8 565 3.40 0.76 15.2
0.09 3.25 2.46 0.75 0.88 12.7 4.04 35.0 8.7 565 3.25 0.88 12.6
0.11 3.28 2.46 0.75 0.86 13.0 4.07 33.2 12.0 565 3.28 0.86 13.0
0.13 3.28 2.46 0.75 0.84 13.3 4.07 32.2 15.0 565 3.28 0.85 13.2
25.0 0.15 3.28 2.46 0.75 0.84 13.4 4.07 31.4 18.0 565 3.28 0.84 13.3
0.15 3.28 2.46 0.75 0.83 13.5 4.07 31.2 18.9 565 3.28 0.84 13.3
0.16 3.31 2.46 0.75 0.83 13.6 4.07 30.8 21.0 565 3.31 0.84 13.4
0.17 3.31 2.46 0.75 0.82 13.7 4.07 30.5 23.4 565 3.31 0.84 13.5
0.18 3.31 2.46 0.75 0.82 13.7 4.07 30.2 25.5 565 3.31 0.84 13.5
0.09 3.14 2.40 0.76 0.96 11.2 3.98 39.8 8.7 565 3.14 0.96 11.2
0.11 3.16 2.40 0.76 0.94 11.5 4.01 38.1 12.0 565 3.16 0.94 11.5
0.13 3.16 2.40 0.76 0.92 11.7 4.01 37.1 15.0 565 3.16 0.93 11.7
30.0 0.15 3.19 2.43 0.76 0.91 11.9 4.01 36.3 18.0 565 3.19 0.92 11.8
0.15 3.19 2.43 0.76 0.91 11.9 4.01 36.1 18.9 565 3.19 0.92 11.8
0.16 3.19 2.43 0.76 0.91 12.0 4.01 35.7 21.0 565 3.19 0.92 11.9
0.17 3.19 2.43 0.76 0.90 12.1 4.01 35.4 23.4 565 3.19 0.92 11.9
0.18 3.19 2.43 0.76 0.90 12.2 4.01 35.1 25.5 565 3.19 0.91 12.0
0.09 3.02 2.34 0.78 1.04 9.9 3.93 44.7 7.8 565 3.02 1.04 9.9
0.11 3.05 2.37 0.77 1.02 10.2 3.93 42.9 10.8 565 3.05 1.02 10.2
0.13 3.08 2.37 0.77 1.01 10.4 3.93 42.0 13.2 565 3.08 1.01 10.3
35.0 0.15 3.08 2.37 0.77 1.00 10.5 3.93 41.3 15.9 565 3.08 1.00 10.5
0.15 3.08 2.37 0.77 0.99 10.6 3.93 41.1 16.8 565 3.08 1.00 10.5
0.16 3.08 2.37 0.77 0.99 10.7 3.96 40.7 18.6 565 3.08 1.00 10.6
0.17 3.08 2.37 0.77 0.98 10.7 3.96 40.3 20.7 565 3.08 0.99 10.6
0.18 3.11 2.37 0.77 0.98 10.8 3.96 40.0 22.8 565 3.11 0.99 10.6
0.09 2.90 2.29 0.79 1.13 8.8 3.81 50.1 7.5 565 2.90 1.13 8.7
0.11 2.90 2.31 0.79 1.11 9.0 3.84 48.3 10.8 565 2.90 1.11 8.9
0.13 2.93 2.31 0.79 1.10 9.1 3.84 47.4 13.2 565 2.93 1.10 9.1
40.6 0.15 2.93 2.31 0.79 1.09 9.2 3.84 46.7 15.9 565 2.93 1.09 9.2
0.15 2.93 2.31 0.79 1.08 9.3 3.84 46.4 16.8 565 2.93 1.09 9.2
0.16 2.96 2.31 0.79 1.08 9.3 3.84 46.1 18.6 565 2.96 1.09 9.2
0.17 2.96 2.31 0.79 1.07 9.4 3.84 45.8 20.4 565 2.96 1.09 9.3
0.18 2.96 2.31 0.79 1.07 9.4 3.87 45.4 22.5 565 2.96 1.08 9.3
0.09 2.75 2.23 0.81 1.22 7.7 3.72 55.6 7.5 565 2.75 1.23 7.7
0.11 2.75 2.23 0.81 1.20 7.9 3.72 53.9 10.5 565 2.75 1.21 7.8
0.13 2.78 2.23 0.80 1.19 8.0 3.72 52.9 12.9 565 2.78 1.20 7.9
46.1 0.15 2.78 2.26 0.80 1.18 8.1 3.72 52.1 15.6 565 2.78 1.19 8.0
0.15 2.78 2.26 0.80 1.18 8.1 3.72 51.9 16.5 565 2.78 1.18 8.0
0.16 2.78 2.26 0.80 1.17 8.2 3.75 51.4 18.6 565 2.78 1.18 8.1
0.17 2.81 2.26 0.80 1.17 8.2 3.75 51.2 20.4 565 2.81 1.18 8.1
0.18 2.81 2.26 0.80 1.16 8.2 3.75 50.9 22.5 565 2.81 1.18 8.1
0.09 2.67 2.17 0.82 1.27 7.2 3.66 58.2 7.5 565 2.67 1.27 7.2
0.11 2.70 2.20 0.82 1.25 7.3 3.66 56.6 10.5 565 2.70 1.25 7.3
0.13 2.70 2.20 0.81 1.24 7.4 3.66 55.6 12.9 565 2.70 1.24 7.4
48.9 0.15 2.70 2.20 0.81 1.23 7.5 3.66 54.8 15.6 565 2.70 1.23 7.5
0.15 2.72 2.20 0.81 1.22 7.6 3.66 54.6 16.5 565 2.72 1.23 7.5
0.16 2.72 2.20 0.81 1.22 7.6 3.66 54.2 18.3 565 2.72 1.23 7.5
0.17 2.72 2.20 0.81 1.22 7.6 3.69 53.8 20.4 565 2.72 1.23 7.6
0.18 2.72 2.20 0.81 1.21 7.7 3.69 53.6 22.5 565 2.72 1.23 7.6
