Performance
Data
Tabulated performance data is tabulated for heating at 68 F [20 C] DB entering air at ARI-ISO 13256-1 rated CFM.
Multipliers must be used to correct performance at conditions other than those tabulated. Data shown in
BOLD
type is performance and
multipliers at ARI-ISO 13256-1 WLHP and GLHP conditions.
RATED GPM: 2.3 MINIMUM CFM: 240 RATED CFM: 300 MAXIMUM CFM: 300
Table PD-5 – 009 Heating Performance
Htg Cap Absorb Power Ft. ISO Cap ISO Pwr ISO
EWT GPM Mbtuh Mbtuh kW COP LWT Hd CFM Mbtuh kW COP
1.5 6.8 4.9 0.78 2.5 15.6 3.0 333 6.8 0.79 2.5
1.8 7.1 5.2 0.79 2.6 17.5 4.1 333 7.1 0.80 2.6
2.1 7.3 5.4 0.80 2.7 18.7 5.0 333 7.3 0.81 2.6
25 2.3 7.5 5.5 0.81 2.7 19.7 6.0 333 7.5 0.82 2.7
2.4 7.5 5.6 0.81 2.7 19.9 6.3 333 7.5 0.82 2.7
2.6 7.6 5.7 0.81 2.8 20.4 7.1 333 7.6 0.82 2.7
2.7 7.8 5.8 0.82 2.8 20.8 7.8 333 7.8 0.83 2.7
2.9 7.8 5.9 0.82 2.8 21.1 8.6 333 7.8 0.83 2.8
1.5 7.9 6.0 0.82 2.8 24.8 3.0 333 7.9 0.82 2.8
1.8 8.2 6.3 0.83 2.9 26.7 4.1 333 8.2 0.84 2.9
2.1 8.4 6.4 0.84 2.9 27.9 5.0 333 8.4 0.84 2.9
35 2.3 8.6 6.6 0.84 3.0 28.9 6.0 333 8.6 0.85 3.0
2.4 8.7 6.7 0.85 3.0 29.1 6.3 333 8.7 0.86 3.0
2.6 8.8 6.8 0.85 3.0 29.6 7.1 333 8.8 0.86 3.0
2.7 8.9 6.9 0.85 3.1 30.0 7.8 333 8.9 0.87 3.0
2.9 9.0 7.0 0.86 3.1 30.3 8.6 333 9.0 0.87 3.0
1.5 9.1 7.1 0.86 3.1 34.0 3.0 333 9.1 0.86 3.1
1.8 9.4 7.4 0.87 3.2 35.9 4.1 333 9.4 0.88 3.1
2.1 9.6 7.6 0.88 3.2 37.1 5.0 333 9.6 0.88 3.2
45 2.3 9.8 7.8 0.88 3.2 38.0 6.0 333 9.8 0.89 3.2
2.4 9.9 7.8 0.89 3.3 38.3 6.3 333 9.9 0.90 3.2
2.6 10.0 7.9 0.89 3.3 38.8 7.1 333 10.0 0.90 3.2
2.7 10.1 8.0 0.89 3.3 39.2 7.8 333 10.1 0.91 3.3
2.9 10.2 8.1 0.90 3.3 39.5 8.6 333 10.2 0.91 3.3
1.5 10.5 8.4 0.91 3.4 43.8 2.9 333 10.5 0.91 3.4
1.8 10.7 8.6 0.91 3.4 45.6 4.1 333 10.7 0.92 3.4
2.1 10.9 8.8 0.92 3.5 46.6 5.0 333 10.9 0.93 3.4
55 2.3 11.0 9.0 0.93 3.5 47.3 6.0 333 11.0 0.93 3.5
2.4 11.1 9.0 0.93 3.5 47.5 6.3 333 11.1 0.94 3.5
2.6 11.2 9.1 0.93 3.5 48.0 7.1 333 11.2 0.94 3.5
2.7 11.3 9.2 0.93 3.5 48.4 7.8 333 11.3 0.95 3.5
2.9 11.4 9.3 0.94 3.6 48.7 8.6 333 11.4 0.95 3.5
1.5 11.9 9.8 0.95 3.7 54.9 2.9 333 11.9 0.96 3.6
1.8 12.2 10.1 0.96 3.7 57.0 4.1 333 12.2 0.97 3.7
2.1 12.4 10.3 0.97 3.7 58.1 5.0 333 12.4 0.98 3.7
68 2.3 12.6 10.5 0.98 3.8 59.0 6.0 333 12.6 0.99 3.7
2.4 12.7 10.5 0.98 3.8 59.3 6.3 333 12.7 0.99 3.7
2.6 12.8 10.6 0.98 3.8 59.8 7.0 333 12.8 1.00 3.8
2.7 12.9 10.7 0.99 3.8 60.2 7.8 333 12.9 1.00 3.8
2.9 13.0 10.8 0.99 3.8 60.6 8.6 333 13.0 1.01 3.8
1.5 12.9 10.8 0.99 3.8 62.6 2.9 333 12.9 0.99 3.8
1.8 13.3 11.1 1.00 3.9 64.8 4.0 333 13.3 1.00 3.9
2.1 13.5 11.3 1.01 3.9 66.1 5.0 333 13.5 1.01 3.9
77 2.3 13.7 11.5 1.01 4.0 67.1 6.0 333 13.7 1.02 3.9
2.4 13.8 11.6 1.02 4.0 67.4 6.3 333 13.8 1.03 3.9
2.6 13.9 11.7 1.02 4.0 67.9 7.0 333 13.9 1.03 3.9
2.7 14.0 11.8 1.03 4.0 68.4 7.8 333 14.0 1.04 4.0
2.9 14.1 11.9 1.03 4.0 68.8 8.5 333 14.1 1.05 4.0
1.5 13.9 11.7 1.02 4.0 70.2 2.9 333 13.9 1.03 4.0
1.8 14.3 12.1 1.04 4.1 72.7 4.0 333 14.3 1.04 4.0
2.1 14.6 12.4 1.04 4.1 74.0 5.0 333 14.6 1.05 4.1
86 2.3 14.8 12.6 1.05 4.1 75.1 6.0 333 14.8 1.06 4.1
2.4 14.9 12.7 1.06 4.1 75.4 6.3 333 14.9 1.06 4.1
2.6 15.0 12.8 1.06 4.2 76.0 7.0 333 15.0 1.07 4.1
2.7 15.2 12.9 1.06 4.2 76.5 7.8 333 15.2 1.08 4.1
2.9 15.3 13.1 1.07 4.2 77.0 8.5 333 15.3 1.08 4.1
Table 6 – Fan Correction Factors – Model GECA 009
Entering Cooling Sensible Cooling Input Heating Heating Input
CFM Capacity Capacity Watts Capacity Watts
267 0.963 0.937 0.998 0.978 1.068
333 1.000 1.000 1.000 1.000 1.000
