82 WSHP-PRC001-EN
Performance Data
300-Cooling (0.65 ESP)
Table P-54: GEV 300 Cooling Performance
Performance data is tabulated for cooling at 80.6 F DB/66.2 F WB entering air at ARI/ISO 13256-1 rated CFM.
For conditions other than what is tabulated, multipliers must be used to correct performance. See the fan correction factors Table for CFM
other than rated and the cooling correction factors for variations in entering air temperature. Data shown in bold type is performance data
at ARI/ISO 13256-1 WLHP and GLHP water only conditions. Antifreeze correction factors may be found on page 108.
RATED GPM: 75.0 MINIMUM CFM: 8000 RATED ESP (in. H20): 0.65
RATED CFM: 10000 MAXIMUM CFM: 12000
EWT GPM Total
Mbtuh
Sen
Mbtuh
SHR Power
kW
Reject
Mbtuh
LWT Feet
Head
PSID
Head
SCFM ISO Cap
Mbtuh
ISO
Power
kW
ISO EER
45
37.5 310.9 234.4 0.75 20.48 380.8 65.3 4.2 1.82
10000
319.6 18.03 17.7
50.0 311.5 234.6 0.75 20.35 381.0 60.2 6.7 2.92 320.2 18.02 17.8
62.5 312.3 234.9 0.75 20.24 381.4 57.2 9.7 4.22 321.0 18.08 17.8
75.0 313.2 235.3 0.75 20.14 381.9 55.2 13.2 5.70 321.9 18.21 17.7
87.5 313.9 235.6 0.75 20.06 382.4 53.7 17.0 7.34 322.6 18.44 17.5
55
37.5 302.4 230.8 0.76 21.50 375.8 75.0 4.2 1.82
10000
311.1 19.05 16.3
50.0 303.0 231.0 0.76 21.32 375.8 70.0 6.7 2.92 311.7 18.98 16.4
62.5 303.9 231.4 0.76 21.16 376.1 67.0 9.7 4.22 312.6 19.00 16.5
75.0 304.8 231.8 0.76 21.02 376.5 65.0 13.2 5.70 313.5 19.10 16.4
87.5 305.8 232.2 0.76 20.90 377.1 63.6 17.0 7.34 314.5 19.28 16.3
68
37.5 290.1 225.6 0.78 23.18 369.2 87.7 4.2 1.81
10000
298.8 20.73 14.4
50.0 290.7 225.8 0.78 22.94 369.0 82.8 6.7 2.91 299.4 20.60 14.5
62.5 291.6 226.2 0.78 22.73 369.2 79.8 9.7 4.21 300.3 20.57 14.6
75.0 292.6 226.6 0.77 22.54 369.5 77.9 13.1 5.69 301.3 20.62 14.6
87.5 293.7 227.1 0.77 22.37 370.0 76.5 16.9 7.33 302.4 20.76 14.6
GLHP
77
37.5 281.1 221.8 0.79 24.61 365.9 94.6 4.2 1.81
10000
289.7 22.16 13.1
50.0 281.7 222.1 0.79 24.32 365.6 89.7 6.7 2.91 290.4 21.99 13.2
62.5 282.6 222.4 0.79 24.08 365.7 86.7 9.7 4.20 291.3 21.91 13.3
75.0 283.6 222.9 0.79 23.86 365.9 84.8 13.1 5.67 292.3 21.93 13.3
87.5 284.6 223.3 0.78 23.65 366.3 83.4 16.9 7.32 293.3 22.03 13.3
WLHP
86
37.5 271.7 218.0 0.80 26.28 361.4 105.4 4.2 1.81
10000
280.4 23.83 11.8
50.0 272.3 218.2 0.80 25.94 360.8 100.5 6.7 2.90 281.0 23.61 11.9
62.5 273.2 218.6 0.80 25.66 360.8 97.6 9.7 4.19 281.9 23.49 12.0
75.0 274.2 219.0 0.80 25.40 360.9 95.7 13.1 5.66 282.9 23.47 12.1
87.5 275.3 219.4 0.80 25.16 361.2 94.3 16.9 7.30 284.0 23.55 12.1
95
37.5 262.1 214.0 0.82 28.19 358.3 114.2 4.2 1.80
10000
270.8 25.74 10.5
50.0 262.7 214.3 0.82 27.81 357.6 109.4 6.7 2.89 271.4 25.47 10.7
62.5 263.7 214.6 0.81 27.49 357.5 106.5 9.7 4.18 272.3 25.32 10.8
75.0 264.7 215.1 0.81 27.19 357.5 104.6 13.0 5.65 273.4 25.26 10.8
87.5 265.7 215.5 0.81 26.92 357.6 103.2 16.8 7.28 274.4 25.30 10.8
105
37.5 251.0 209.5 0.83 30.58 355.4 124.1 4.1 1.79
10000
259.6 28.13 9.2
50.0 251.5 209.7 0.83 30.15 354.4 119.3 6.7 2.88 260.2 27.81 9.4
62.5 252.5 210.1 0.83 29.79 354.2 116.4 9.6 4.17 261.2 27.62 9.5
75.0 253.6 210.5 0.83 29.46 354.1 114.5 13.0 5.63 262.2 27.53 9.5
87.5 254.6 211.0 0.83 29.15 354.1 113.2 16.8 7.26 263.3 27.53 9.6
115
37.5 239.2 204.7 0.86 33.28 352.8 134.0 4.1 1.79
10000
247.9 30.83 8.0
50.0 239.8 204.9 0.85 32.79 351.7 129.2 6.6 2.87 248.5 30.46 8.2
62.5 240.8 205.3 0.85 32.40 351.4 126.4 9.6 4.15 249.5 30.23 8.3
75.0 241.9 205.8 0.85 32.03 351.2 124.5 12.9 5.61 250.5 30.09 8.3
87.5 243.0 206.2 0.85 31.69 351.2 123.1 16.7 7.23 251.7 30.06 8.4
120
37.5 233.1 202.3 0.87 34.74 351.7 139.0 4.1 1.78
10000
241.8 32.29 7.5
50.0 233.7 202.5 0.87 34.24 350.6 134.2 6.6 2.87 242.4 31.90 7.6
62.5 234.7 202.9 0.86 33.82 350.1 131.3 9.6 4.14 243.4 31.65 7.7
75.0 235.8 203.4 0.86 33.44 349.9 129.4 12.9 5.59 244.5 31.50 7.8
87.5 237.0 203.8 0.86 33.08 349.9 128.1 16.7 7.21 245.6 31.45 7.8
