Trane GEVE - Page 82

82
WSHP-SVX01AA-EN
Table 49. Electrical data high static motors 0.5 to 5 tons (continued)
Model No. Volts
Total
Unit FLA
Comp
RLA (ea)
Comp
LRA (ea)
No. of
Comp.
Blower
Motor
FLA
Blower
Motor hp
Fan
Motor
Num
Mini- mum
Circuit
Ampaci-
ty
Maxi-
mum
Overcur-
rent
Protec-
tive
Device
Electric
Heat kW
Electric
Heat
Amps
GEHE042
575/60/3
6.2 4.9 34 1 1.31
1/2
1 7.44 15 0.0 0.0
GEHE048
208/60/1
26.8 21.4 135 1 5.40 1 1 32.15 50 0.0 0.0
GEHE048
208/60/1
36.7 21.4 135 1 5.40 1 1 45.81 50 6.5 31.3
GEHE048
230/60/1
26.8 21.4 135 1 5.40 1 1 32.15 50 0.0 0.0
GEHE048
230/60/1
40.2 21.4 135 1 5.40 1 1 50.23 60 8.0 34.8
GEHE048
208/60/3
19.9 14.5 98 1 5.40 1 1 23.53 35 0.0 0.0
GEHE048
208/60/3
23.4 14.5 98 1 5.40 1 1 29.30 35 6.5 18.0
GEHE048
230/60/3
19.9 14.5 98 1 5.40 1 1 23.53 35 0.0 0.0
GEHE048
230/60/3
25.5 14.5 98 1 5.40 1 1 31.85 35 8.0 20.1
GEHE048
460/60/3
9.0 6.3 55 1 2.70 1 1 10.58 15 0.0 0.0
GEHE048
460/60/3
16.0 6.3 55 1 2.70 1 1 20.01 25 10.6 13.3
GEHE048
575/60/3
8.2 6 41 1 2.20 1 1 9.70 15 0.0 0.0
GEHE060
208/60/1
31.7 26.3 134 1 5.40 1 1 38.28 60 0.0 0.0
GEHE060
208/60/1
36.7 26.3 134 1 5.40 1 1 45.81 60 6.5 31.3
GEHE060
230/60/1
31.7 26.3 134 1 5.40 1 1 38.28 60 0.0 0.0
GEHE060
230/60/1
40.2 26.3 134 1 5.40 1 1 50.23 60 8.0 34.8
GEHE060
208/60/3
21.0 15.6 110 1 5.40 1 1 24.90 40 0.0 0.0
GEHE060
208/60/3
23.4 15.6 110 1 5.40 1 1 29.30 40 6.5 18.0
GEHE060
230/60/3
21.0 15.6 110 1 5.40 1 1 24.90 40 0.0 0.0
GEHE060
230/60/3
25.5 15.6 110 1 5.40 1 1 31.85 40 8.0 20.1
GEHE060
460/60/3
10.5 7.8 52 1 2.70 1 1 12.45 20 0.0 0.0
GEHE060
460/60/3
16.0 7.8 52 1 2.70 1 1 20.01 25 10.6 13.3
GEHE060
575/60/3
8.0 5.8 38.9 1 2.20 1 1 9.45 15 0.0 0.0
EElleeccttrriiccaall DDaattaa
