Trane GEVE - Page 83

WSHP-SVX01AA-EN
83
Table 50. Electrical data - ECM motors - 0.5 to 5 tons GEV
Model
No.
Unit
Volts
Total
Unit FLA
Comp
RLA
(ea)
Comp
LRA
(ea)
Blower
Motor
FLA
Blower
Motor
HP
Mini- mum
Circuit
Ampaci-
ty
Maxi-
mum
Overcur-
rent
Protec-
tive
Device
Electric
Heat
Kw
Electric
Heat
Amps
GEVG006
208-230/60/1
3.9 3.6 27.0 0.3
1/3 5/5 15/15
0.0 0.0
GEVG006
265/60/1
3.3 3.0 22.0 0.3
1/3
5 15 0.0 0.0
GEVG009
208-230/60/1
4.7 4.0 27.0 0.7
1/3 6/6 15/15
0.0 0.0
GEVG009
265/60/1
3.9 3.3 22.0 0.6
1/3
5 15 0.0 0.0
GEVG012
208-230/60/1
6.6 5.7 27.0 0.9
1/3 9/9 15/15
0.0 0.0
GEVG012
265/60/1
5.3 4.5 32.0 0.8
1/3
7 15 0.0 0.0
GEVG015
208-230/60/1
8.2 7.3 36.0 0.9
1/3 10/10 15/15
0.0 0.0
GEVG015
265/60/1
5.6 4.8 30.0 0.8
1/3
7 15 0.0 0.0
GEVG018
208-230/60/1
9.7 8.5 38.0 1.2
1/3 12/12 20/20
0.0 0.0
GEVG018
265/60/1
7.8 6.8 35.0 1.0
1/3
10 15 0.0 0.0
GEVG024
208-230/60/1
15.2 13.5 58.3 1.7
1/2 19/19 30/30
0.0 0.0
GEVG024
265/60/1
10.4 9.0 54.0 1.4
1/2
13 20 0.0 0.0
GEVG024
208-230/60/3
8.8 7.1 55.4 1.7
1/2 11/11 15/15
0.0 0.0
GEVG024
460/60/3
4.3 3.5 28.0 0.8
1/2
6 15 0.0 0.0
GEVG030
208-230/60/1
15.9 14.1 73.0 1.8
3/4 20/20 30/30
0.0 0.0
GEVG030
208-230/60/3
10.7 8.9 58.0 1.8
3/4 13/13 20/20
0.0 0.0
GEVG030
265/60/1
12.8 11.2 60.0 1.6
3/4
16 25 0.0 0.0
GEVG030
460/60/3
5.1 4.2 28.0 0.9
3/4
7 15 0.0 0.0
GEVG036
208-230/60/1
19.3 16.7 79.0 2.7
3/4 24/24 40/40
0.0 0.0
GEVG036
265/60/1
15.8 13.5 72.0 2.3
3/4
20 30 0.0 0.0
GEVG036
208-230/60/3
13.1 10.4 73.0 2.7
3/4 16/16 25/25
0.0 0.0
GEVG036
460/60/3
7.1 5.8 38.0 1.3
3/4
9 15 0.0 0.0
GEVG042
208-230/60/1
21.2 17.9 112.0 3.3
3/4 26/26 40/40
0.0 0.0
GEVG042
208-230/60/3
16.8 13.5 88.0 3.3
3/4 21/21 30/30
0.0 0.0
GEVG042
460/60/3
7.6 6.0 44.0 1.6 1 10 15 0.0 0.0
GEVG048
208-230/60/1
25.3 21.4 135.0 4.0 1
31/31 50/50
0.0 0.0
GEVG048
208-230/60/3
18.5 14.5 98.0 4.0 1
23/23 35/35
0.0 0.0
EElleeccttrriiccaall DDaattaa
