50
MUA-SVX003B-EN
Double Wall Construction Adder
For units ordered with double wall construction: add an additional 10% to the base unit weight.
Cooling Coil Weight Adder
Table 5. Cooling Coil Weight Adder
Capacity
DX Coil Chilled Water Coil
4 Row 6 Row 4 Row 6 Row
10, 15
97 lbs. 132 lbs. 75 lbs. 102 lbs.
20, 25, 50
126 lbs. 177 lbs. 98 lbs. 135 lbs.
30, 35, 60, 70
165 lbs. 229 lbs. 125 lbs. 176 lbs.
40, 80
177 lbs
. 249 lbs. 135 lbs. 196 lbs.
UUnniitt NNeett && SShhiipp WWeeiigghhttss
