FFiilltteerr LLaayyoouuttss
Table 58. 2" and 4" panel filters (20-30 ton)
16x20 16x20 16x20 16x20
20x20 20x20 20x20 20x24
20x20 20x20 20x20 20x24
Table 59. 2" and 4" panel filters (40-55 ton)
20x20 20x20 20x20 20x24
20x24 20x24 20x24 24x24
20x24 20x24 20x24 24x24
Table 60. 2" and 4" panel filters (60S, 60H/V, 70S ton)
20x20 20x20 20x24 20x24 20x24
20x24 20x24 24x24 24x24 24x24
20x24 20x24 24x24 24x24 24x24
Table 61. 2" and 4" panel filters (70H/V, 75S, 75H/V ton)
20x24 20x24 20x24 24x24 24x24
20x24 20x24 20x24 24x24 24x24
Table 62. Cartridge filters (20-30 ton)
16x20 16x20 16x20 16x20
20x20 20x20 20x24 20x24
20x20 20x20 20x24 20x24
Table 63. Cartridge filters (40-55 ton)
20x20 20x20 20x24 20x24
20x24 20x24 24x24 24x24
20x24 20x24 24x24 24x24
Table 64. Cartridge filters (60-75 ton)
20x20 20x20 20x24 20x24 20x24
20x24 20x24 24x24 24x24 24x24
20x24 20x24 24x24 24x24 24x24
Table 65. Final filters (20-30 ton)
16x20 16x20 16x20 16x20
20x20 20x20 20x24 20x24
20x20 20x20 20x24 20x24
