Table 2. Roof curb dimensional data (inches)
Description
A B C E F G K L M N R S U V W X
RX, 20-30 T, PANEL
FILTER
169.99 84.50 3.58 24.62 76.49 3.60 27.00 67.50 111.19 18.97 95.94 94.50 170.31 84.82 59.80 97.89
RX, 20-30 T, PANEL
FILTER, RELFAN
200.97 84.50 33.05 26.13 76.49 3.60 27.00 67.50 111.19 18.97 95.94 94.50 201.29 84.82 90.78 128.88
RX, 20-30 T, CART
FILTER
188.99 84.50 3.58 24.62 76.49 3.60 27.00 67.50 130.19 18.97 95.94 94.50 189.31 84.82 80.01 116.89
RX, 20-30 T, CART
FILTER, RELFAN
219.97 84.50 33.05 26.13 76.49 3.60 27.00 67.50 130.19 18.97 95.94 94.50 220.29 84.82 111.04 147.88
RA, 20-30 T, PANEL
FILTER
120.26 84.50 3.58 24.62 76.49 23.85 28.50 76.49 39.72 18.97 95.94 94.50 120.58 84.82 60.67 98.55
RA, 20-30 T, PANEL
FILTER, RELFAN
151.25 84.50 33.05 26.13 76.49 23.85 28.50 76.49 39.72 18.97 95.94 94.50 151.57 84.82 91.83 129.56
RA, 20-30 T, CART
FILTER
139.26 84.50 3.58 24.62 76.49 23.85 28.50 76.49 58.72 18.97 95.94 94.50 139.58 84.82 79.85 117.58
RA, 20-30 T, CART
FILTER, RELFAN
170.25 84.50 33.05 26.13 76.49 23.85 28.50 76.49 58.72 18.97 95.94 94.50 170.57 84.82 110.82 148.56
RX, 40-55 T, PANEL
FILTER
179.99 84.50 3.58 32.12 76.49 3.60 29.50 67.50 111.19 59.12 95.94 94.50 180.31 84.82 67.30 105.39
RX, 40-55 T, PANEL
FILTER, RELFAN
210.97 84.50 33.05 33.63 76.49 3.60 29.50 67.50 111.19 59.12 95.94 94.50 211.29 84.82 98.29 136.38
RX, 40-55 T, CART
FILTER
198.99 84.50 3.58 32.12 76.49 3.60 29.50 67.50 130.19 59.12 95.94 94.50 199.31 84.82 87.55 124.39
RX, 40-55 T, CART
FILTER, RELFAN
229.97 84.50 33.05 33.63 76.49 3.60 29.50 67.50 130.19 59.12 95.94 94.50 230.29 84.82 118.54 155.38
RA, 40-55 T, PANEL
FILTER
127.76 84.50 3.58 32.12 76.49 23.85 28.50 76.49 39.72 59.12 95.94 94.50 128.08 84.82 68.30 106.05
RA, 40-55 T, PANEL
FILTER, RELFAN
158.75 84.50 33.05 33.63 76.49 23.85 28.50 76.49 39.72 59.12 95.94 94.50 159.07 84.82 99.29 137.03
RA, 40-55 T, CART
FILTER
146.76 84.50 3.58 32.12 76.49 23.85 28.50 76.49 58.72 59.12 95.94 94.50 147.08 84.82 87.30 125.05
RA, 40-55 T, CART
FILTER, RELFAN
177.75 84.50 33.05 33.63 76.49 23.85 28.50 76.49 58.72 59.12 95.94 94.50 178.07 84.82 118.29 156.03
RX, 60-75 T, PANEL
FILTER
179.99 110.00 3.58 32.12 101.99 3.60 29.50 93.00 111.19 59.12 121.44 120.00 180.31 110.32
RX, 60-75 T, PANEL
FILTER, RELFAN
216.48 110.00 38.56 33.63 101.99 3.60 29.50 93.00 111.19 59.12 121.44 120.00 216.80 110.32
RX, 60-75 T, CART
FILTER
198.99 110.00 3.58 32.12 101.99 3.60 29.50 93.00 130.19 59.12 121.44 120.00 199.31 110.32
RX, 60-75 T, CART
FILTER, RELFAN
235.48 110.00 38.56 33.63 101.99 3.60 29.50 93.00 130.19 59.12 121.44 120.00 235.80 110.32
RA, 60-75 T, PANEL
FILTER
127.76 110.00 3.58 32.12 101.99 22.85 29.50 101.99 39.72 59.12 121.44 120.00 128.08 110.32
RA, 60-75 T, PANEL
FILTER, RELFAN
164.25 110.00 38.56 33.63 101.99 22.85 29.50 101.99 39.72 59.12 121.44 120.00 164.57 110.32
RA, 60-75 T, CART
FILTER
146.76 110.00 3.58 32.12 101.99 22.85 29.50 101.99 58.72 59.12 121.44 120.00 147.08 110.32
RA, 60-75 T, CART
FILTER, RELFAN
183.25 110.00 38.56 33.63 101.99 22.85 29.50 101.99 58.72 59.12 121.44 120.00 183.57 110.32
RX, 60-75 T, PANEL
FILTER, STGEV
227.99 110.00 3.58 32.12 101.99 3.60 29.50 93.00 159.19 59.12 121.44 120.00 228.31 110.32
RX, 60-75 T, PANEL
FILTER, RELFAN,
STGEV
264.48 110.00 38.56 33.63 101.99 3.60 29.50 93.00 159.19 59.12 121.44 120.00 264.80 110.32
RX, 60-75 T, CART
FILTER, STGEV
258.99 110.00 3.58 32.12 101.99 3.60 29.50 93.00 190.19 59.12 121.44 120.00 259.31 110.32
RX, 60-75 T, CART
FILTER, RELFAN,
STGEV
295.48 110.00 38.56 33.63 101.99 3.60 29.50 93.00 190.19 59.12 121.44 120.00 295.80 110.32
RA, 60-75 T, PANEL
FILTER, STGEV
175.76 110.00 3.58 32.12 101.99 22.85 29.50 101.99 87.72 59.12 121.44 120.00 176.08 110.32
RA, 60-75 T, PANEL
FILTER, RELFAN,
STGEV
212.25 110.00 38.56 33.63 101.99 22.85 29.50 101.99 87.72 59.12 121.44 120.00 212.57 110.32
RA, 60-75 T, CART
FILTER, STGEV
206.76 110.00 3.58 32.12 101.99 22.85 29.50 101.99 118.72 59.12 121.44 120.00 207.08 110.32
RA, 60-75 T, CART
FILTER, RELFAN,
STGEV
243.25 110.00 38.56 33.63 101.99 22.85 29.50 101.99 118.72 59.12 121.44 120.00 243.57 110.32
Note: High efficiency and eFlex
TM
refrigeration system performance for both 70 and 75 tons have a staggered evaporator coil (STGEV).
