RT-SVX063E-EN

Table 41. Compressor staging — 25S, 30S

Stage Comp 1A Comp 1B Comp 1C

1 ON — —

2 — ON —

3 ON ON —

4 — ON ON

5 ON ON ON

Table 42. Compressor staging — 20H, 25H, 30H

Stage Comp 1A Comp 1B

1 ON —

2 — ON

3 ON ON

Table 43. Compressor staging — 40S, 40H, 50S, 50H,

55S, 55H, 60S, 60H, 70S, 70H, 75S, 75H

Stage Comp 1A Comp 1B Comp 2A Comp 2B

1 ON — — —

2 ON — ON —

3 ON ON ON —

4 ON ON ON ON

Table 44. Compressor staging — 20V

Capacity

Step

Comp 1A

(a)

Comp 1B Speed

Min

Speed

Max

1 ON — 1500 5670

2 ON ON 1500 5190

(a)

Variable Speed Compressor.

Table 45. Compressor staging — 25V

Capacity

Step

Comp 1A

(a)

Comp 1B

Speed

Min

Speed

Max

1 ON — 1620 6000

2 ON ON 1500 6000

(a)

Variable Speed Compressor.

Table 46. Compressor staging — 30V

Capacity

Step

Comp 1A

(a)

Comp 1B Speed

Min

Speed

Max

1 ON — 1500 6000

2 ON ON 1500 5010

(a)

Variable Speed Compressor.

Table 47. Compressor staging — 40V

Ca-

pacity

Step

Comp

(a)

Comp

Speed

Min

Speed

Max

1 ON — — 1800 5202

2 ON ON — 1998 5400

3 ON ON ON 2520 5940

(a)

Variable Speed Compressor.

Table 48. Compressor staging — 50V

Ca-

pacity

Step

Comp

(a)

Comp

Speed

Min

Speed

Max

1 ON — — 1590 4500

2 ON ON — 1500 4590

3 ON ON ON 2160 4590

(a)

Variable Speed Compressor.

Table 49. Compressor staging — 55V

Ca-

pacity

Step

Comp

(a)

Comp

Speed

Min

Speed

Max

1 ON — — 1662 4380

2 ON ON — 1500 4860

3 ON ON ON 2340 4860

(a)

Variable Speed Compressor.

Table 50. Compressor staging — 60V

Ca-

pacity

Step

Comp

(a)

Comp

Speed

Min

Speed

Max

1 ON — — 1950 4980

2 ON ON — 1500 5550

3 ON ON ON 2580 5550

(a)

Variable Speed Compressor.

Table 51. Compressor staging — 70V

Ca-

pacity

Step

Comp

(a)

Comp

Speed

Min

Speed

Max

1 ON — — 2010 4860

2 ON ON — 1500 4980

3 ON ON ON 2220 6000

(a)

Variable Speed Compressor.

CCoonnttrroollss
