Trane IntelliPak RA 20 User Manual

RT-SVX063E-EN
99
Figure 50. 40, 50 and 55 ton, 24.5 inch - 9 blade - 80%
width supply fan
2100 RPM
2000 RPM
1900 RPM
1800 RPM
1300 RPM
1700 RPM
1600 RPM
1500 RPM
1200 RPM
1100 RPM
1400 RPM
950 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
0 2500 5000 7500 10000 12500 15000 17500 20000 22500 25000 27500
Sta!c Pressure, Inches w.c.
Airflow, CFM
NNoottee:: Maximum airflow (for cULus approval) as
follows: 40 ton - 18,000 CFM, 50/55 ton - 24,750
CFM
Figure 51. 40, 50 and 55 ton, 24.5 inch - 9 blade - 100%
width supply fan
2000 RPM
1900 RPM
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
950 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
0 2500 5000 7500 10000 12500 15000 17500 20000 22500 25000 27500
Sta!c Pressure, Inches w.c.
Airflow, CFM
NNoottee:: Maximum airflow (for cULus approval) as
follows: 40 ton - 18,000 CFM, 50/55 ton - 24,750
CFM
Figure 52. 60, 70 and 75 ton, 22.2 inch - 9 blade - 100%
width supply fan
2200 RPM
2100 RPM
2000 RPM
1900 RPM
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
1000 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
0 2500 5000 7500 10000 12500 15000 17500 20000 22500 25000 27500 30000
Sta!c Pressure, Inches w.c.
Airflow, CFM
NNoottee:: Maximum airflow (for cULus approval) as
follows: 60 ton - 27,000 CFM, 70/75 ton - 30,000
CFM
Figure 53. 60 and 75 ton, 27.0 inch - 9 blade - 100%
width supply fan
1800 RPM
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
950 RPM
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
0 2500 5000 7500 10000 12500 15000 17500 20000 22500 25000 27500 30000 32500
Sta!c Pressure, Inches w.c.
Airflow, CFM
NNoottee:: Maximum airflow (for cULus approval) as
follows: 60 ton - 27,000 CFM, 70/75 ton - 30,000
CFM
PPeerrffoorrmmaannccee DDaattaa
