Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN 11
General
InformationProgramming
General Status Display
Anytime the self-contained unit is
powered up or when the STATUS, AUTO,
or STOP keys are pressed, the unit
mounted HI will display one of four
general status display screens. This will
allow the user to navigate through a set
of menus and submenus to provide or
access various monitoring, setup, and
configuration information. The HI will not
display screens that the unit is not
configured for.
Top Level State
(Unit Off)
(Unit Stopped)
(External Stop)
(Emergency Stop)
(Unit Starting)
(Service Mode On)
___________________
____________ _____________
Function in Operation
(Blank)
(Shutdown)
(Check Config)
(Invalid Cfg)
Trouble Indicator
(Blank)
(Diagnostics)
1. Unit “Off” or “Stopped”
If at power up the unit is not running, the following display will appear. When this
screen displays, the only functional keys are the menu keys (STATUS, SETPOINTS,
DIAGNOSTICS, SETUP, CONFIGURATION, and SERVICE MODE), the AUTO key, the
CUSTOM key, and the STOP key.
2. Unit “On”
If the unit has entered an operating state (running), the following display will appear.
When this screen displays, the only functional keys are the menu keys (STATUS,
SETPOINTS, DIAGNOSTICS, SETUP, CONFIGURATION, AND SERVICE MODE), the
AUTO key, the CUSTOM key, and the STOP key.
VAV OA Flow
___
CFM Supply Fan
____
___________ _______ ____________
Unit Type
(CV)
(VAV)
Mode of Operation
(Occupied)
(Daytime WU)
(Morning WU)
(Standby)
(Unoccupied)
(Shutdown)
(Initializing)
(Blank)
Function Stage
(Heat)
(Cool)
(O/A Dmpr)
(Blank)
Trouble Indicator
(Blank)
(Diagnostics Present)
Fan Mode
(On)
(Off)
Range
0-600
Function in Operation
O/A Flow (CCFM)
Unoccupied
(Blank if supply fan off or no VCM)
