Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN 15
General
InformationProgramming
Table P-GI-5. Module Defaults.
Factory Preset Changed to: Reference Page #
GBAS input/output assignments
GBAS input/output not assigned 46
Information format
Text displays English 32
Unit displays English 32
Reference Enthalpy 25 btu/lb. 59
RTM alarm output assignments any active diagnostic 47
Sensor source selection for:
Daytime warmup RTM zone temp 40
Monitor Specified Temp. Input RTM zone temp 42
Morning warmup RTM zone temp 41
Unoccupied zone control RTM zone temp 41
Zone reset RTM aux temp 41
Setpoint source selection for:
Cooling supply air temp default 60
Heating supply air temp default 61
Morning warmup default 62
Unoccupied zone cooling default 61
Unoccupied zone heating default 61
Actuator setup:
Direct/reverse action direct acting 51-55
Max stroke time 150 seconds 51-55
Max voltage 10 VDC 51-55
Min voltage 2 VDC 51-55
Coil frost cutout temperature 30 F 34
Condenser temperature control band:
Temporary low limit suppression 10 F 39-40
Upper limit 120 F 39-40
Low limit 80 F 39-40
Condenser temperature:
Efficiency check point 105 F 40
Low ambient control point 90 F 40
Control algorithm tuning parameters N/A 56
Max IGV position occupied 100% 37
Temperature input offset for:
Heat morning warmup 0 F 48
Return air 0 F 48
RTM zone temperature 0 F 48
RTM aux. temperature 0 F 48
Outdoor air 0 F 48
Ventilation override definition N/A 43-45
Use Table P-GI-5 to reference module factory setups and keep track of setpoint adjustments. Make necessary adjustments using the
setup key on the HI.
