18
Programming
PKG-SVP01B-EN
(On units with electric heat only)
Electric Heat ENABLED
Stage 1 OFF Stage 2 OFF Stage 3 OFF
Possible values: Off, On
Note: Two or three-stage electric heat is a field-provided option.
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat only)
Hydronic Heat ENABLED 0 %
Low Air Temp Limit OK
Possible values: Hydronic Heat = Enabled, Disabled
Valve position = 0-100% open
Low temp air = OK , tripped
1. Pressing the NEXT key will display the following screen.
(On units with VCM module or Traq™ damper option only)
Active Min OA Flow Setpoint 342.0 CCFM
OA Flow 350.0 CCFM OA Damper Pos 0 %
Possible values: Unit Airflow = 0 to maximum unit airflow
1. Pressing the NEXT key will display the following screen.
(On units with VCM module and CO2 reset enabled)
Active Min OA Flow Setpoint 342.0 CCFM
C02 Level 1512 PPM OA Damper Pos 0 %
Possible values: Unit Airflow = 0 to maximum unit airflow
1. Pressing the NEXT key will display the following screen.
(On units with VCM module and preheat enabled)
OA Preheat Output Control: ON
Possible values: On, Off
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
Compressor Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will display the following screen.
STATUS
To Next Page
