Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN
19
Programming
Compressor Relay K11 OFF
Enabled
Possible values: K11 = Off, On, Locked, Disabled, Enabled
Disabled by: Compressor Protection Frost Protection
Contactor Failure Tracer Summit
®
Lockout
Low Pressure Cutout Minimum Off Time
Bad Cond Temp Sensor Low Ambient Lockout
Demand Limit Ventilation Override
Low Ent Cond water Temp
1. Pressing the NEXT key will display the following screen.
(On units with manifolded refrigerant circuits)
Compressor Relay K12 OFF
Enabled
Possible values: K11 = Off, On, Locked, Disabled, Enabled
Note: On models SCWF/SIWF and SCRF/SIRF units, K12 is the “B” compressor on units
with manifolded refrigerant circuits and “C” compressor on all units with independent
refrigerant circuits. Check unit model number, digit 5 to determine which type circuit the
unit has.
1. Pressing the NEXT key will display the following screen.
(On units with independent refrigerant circuits)
Compressor Relay K3 OFF
Enabled
Possible values: K3 = Off, On, Locked, Disabled, Enabled
Note: On models SCWF/SIWF, 35-80 tons, K3 is the “B” compressor.
1. Pressing the NEXT key will display the following screen.
(On model SCWF/SIWF, 60-80 ton units)
Compressor Relay K4 OFF
Enabled
Possible values: K4 = Off, On, Locked, Disabled, Enabled
Disabled by: Compressor Protection Frost Protection
Contactor Failure Tracer Summit
®
Lockout
Low Pressure Cutout Minimum Off Time
Bad Cond Temp Sensor Low Ambient Lockout
Demand Limit Ventilation Override
Low Ent Cond Water Temp
1. Pressing the NEXT key will display the following screen.
STATUS
