Trane IntelliPak Signature Series Programming Guide

20
Programming
PKG-SVP01B-EN
Active Outside Air Temperature 86.0 F
Low Ambient Comp Lockout Temp: 32 F
Possible values: Lockout Temperature = -20-80 F
1. Pressing the NEXT key will display the following screen.
(
On units all water-cooled units only)
WSM Ent Cond Water Temp Input 65.2 F
Low Water Temp Compressor Lockout 34 F
Possible values: Lockout Temperature = 0-99 F
1. Pressing the NEXT key will display the following screen.
Compressor Module Ckt 1
Evap Temp 75.0 F Sat Cond Temp 81.0 F
1. Pressing the NEXT key will display the following screen.
Compressor Module Ckt 2
Evap Temp 72.0 F Sat Cond Temp 97.0 F
1. Pressing the NEXT key will display the following screen.
(
On all SCWF/SIWF 35-80 ton units only)
Compressor Module Ckt 3
Evap Temp 72.0 F Sat Cond Temp 97.0 F
1.Pressing the NEXT key will display the following screen.
(
On all SCWF/SIWF 60-80 ton units only)
Compressor Module Ckt 4
Evap Temp 72.0 F Sat Cond Temp 97.0 F
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
(
On units with a waterside or airside economizer only)
Economizer Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will display the following screen.
