Programming
( On units with a waterside economizer only)
Water Economizing: DISABLED
Outside Air Damper Pos: 10 %
Possible values: Economizer = Disable, Enable
Water econ position = opening to/closing to 0-100%
1. Pressing the NEXT key will display the following screen.
(
On units with a waterside economizer or condenser only)
WSM Mixed Air Temperature: 68 F
WSM Entering Water Temperature: 60 F
1. Pressing the NEXT key will display the following screen.
(
On units with a waterside economizer and condenser only)
Water Econ Bypass Pos: 10%
Possible values: Water econ position = opening to/closing to 0-100%
1. Pressing the NEXT key will display the following screen.
(
On units with an airside economizer only)
Air Economizing: DISABLED
Outside Air Damper Pos: 0 %
Possible values: Economizer = Disable, Enable
Outside air = opening to/closing to 0-100%
1. Press the NEXT key until the following screen is displayed.
(
On units with an airside economizer and comparative enthalpy only)
Active Outside Air Enthalpy 12.0 BTU/LB
ECEM Return Air Enthalpy 34.0 BTU/LB
Possible values: 10-99 BTU/LB
1. Pressing the NEXT key will display the following screen.
(
On units with an airside economizer only)
Active Outside Air Temperature 86.0 F
ECEM Return Air Temperature 78.0 F
1. Pressing the NEXT key will display the following screen.
STATUS
