Programming
PKG-SVP01B-EN
( On units with an airside economizer only)
Active Outside Air Humidity 30 %
ECEM Return Air Humidity 62 %
Possible values: 0-100%
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
Controlling Setpoint Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will display the following screen.
(On all VAV units only)
Active Supply Air Cooling STP From
HI (KEYPAD) SETPOINT MENU Is 55 F
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Input
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
ICS (Tracer Summit
®
)
1. Pressing the NEXT key will display the following screen.
(On all VAV units with hydronic heat only)
Active Supply Air Heating STP From
HI (KEYPAD) SETPOINT MENU Is 100 F
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Input
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
ICS (Tracer Summit
®
)
1. Pressing the NEXT key will display the following screen.
(On all VAV units with hydronic, electric, or external heat only)
Active Daytime Warmup Setpoints
Initiate: 67 F is Terminate: 71 F
Possible Values: HI (Keypad) Setpoint Menu
1. Pressing the NEXT key will display the following screen.
STATUS
