Page #24 background imageLoading...
Page #24 background image
24
Programming
PKG-SVP01B-EN
(On units with hydronic, electric, or external heat only)
Active Morning Warmup Setpoint From
HI (KEYPAD) SETPOINT MENU is 72 F
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Input
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
ICS (Tracer Summit
®
)
Setpoint Range: 50-90 F
1. Pressing the NEXT key will display the following screen.
(On units with VCM module only)
Active Min OA Flow Setpoint From
REMOTE MIN POS POT INPUT 342.0 CFM
Possible Values: HI (Keypad) Setpoint Menu
GBAS 0-5 VDC Module
Setpoint Range: 0 to max unit airflow
1. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD only)
Active Supply Air Pressure STP From
HI (KEYPAD SETPOINT MENU is 2.0 IWC
Possible Values: HI (Keypad) Setpoint Menu
GBAS Module
1. Pressing the NEXT key will display the following screen.
On units with IGV or VFD only)
Active Supply Air Pressure Setpoints
High Limit: 40 IWC Deadband: 0.5 IWC
Possible Values: High Limit = 1.6-4.7 IWC
Deadband = 0.1-2.0 IWC
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
Controlling Sensor Status Submenu
1. Pressing the NEXT key will display the following screen.
STATUS
