Trane IntelliPak Signature Series - Page 25

PKG-SVP01B-EN
25
Programming
Active Supply Air Temp Sensor Input From
RTM ZONE TEMP INPUT is 50.0 F
Possible Values: RTM Supply Air Temp Input
ICS (Tracer Summit
®
)
1. Pressing the NEXT key will display the following screen.
(On units with hydronic, electric, or external heat only)
Active Daytime WU Temp Sensor Input From
RTM ZONE TEMP INPUT is 82.0 F
Possible Values: RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM return Air Temp Input
ICS (Tracer Summit
®
)
Sensor Range: -40 to 200 F
1. Pressing the NEXT key will display the following screen.
(On units with hydronic, electric, or external heat with DWU installed only)
Active Occupied Zone Temp Sensor Input From
HI (KEYPAD) SETPOINT MENU Is 90 F
Possible Values: RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM return Air Temp Input
ICS (Tracer Summit
®
)
Sensor Range: -40 to 200 F
1. Pressing the NEXT key will display the following screen.
Active Unocc Zone Temp Sensor Input From
RTM ZONE TEMP INPUT is 75.0 F
Possible Values: RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM return Air Temp Input
ICS (Tracer Summit
®
)
Sensor Range: -40 to 200 F
1. Pressing the NEXT key will display the following screen.
(On units with hydronic, electric, or external heat with MWU enabled only)
STATUS
