Trane IntelliPak Signature Series Programming Guide

26
Programming
PKG-SVP01B-EN
Active Morning WU Temp Sensor Input From
RTM ZONE TEMP INPUT is 82.0 F
Possible Values: RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM return Air Temp Input
ICS (Tracer Summit
®
)
Sensor Range: -40 to 200 F
1. Pressing the NEXT key will display the following screen.
Active Zone Reset Sensor Input From
RTM ZONE TEMP INPUT is 82.0 F
Possible Values: RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM Return Air Temp Input
ICS (Tracer Summit
®
)
Sensor Range: -40 to 200 F
1. Pressing the NEXT key will display the following screen.
Active OA Temperature Sensor Input From
RTM OUTSIDE AIR TEMP INPUT is 86.0 F
Possible Values: RTM Outside Air Temp Input
ICS (Tracer Summit
®
)
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Active Outside Air Humidity Input From
OA HUMIDITY SENSOR INPUT is 30 %
Possible Values: O/A Humidity Sensor Input
ICS (Tracer Summit
®
)
Sensor Range: 0-100%
1. Pressing the NEXT key will display the following screen.
(On units with IGV, VFD, or with the SAP sensor enabled)
Active Supply Air Press Sensor Input From
RTM SA PRESSURE INPUT is 2.1 IWC
Possible Values: RTM SA Pressure Input
ICS (Tracer Summit
®
)
1. Pressing the NEXT key will display the following screen.
