PKG-SVP01B-EN
27
Programming
Temp Sensor Input Being Monitored:
RTM ZONE TEMP INPUT is 82.0 F
Possible Values: RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM Return Air Temp Input
ICS (Tracer Summit
®
)
No sensor selected
Sensor Range: -40 to 200 F
1. Pressing the NEXT key will display the following screen.
End of Submenu (NEXT) to Enter SETUP
1. Pressing the NEXT key will display the following screen.
Temperature Input Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will display the following screen.
Temp Measured By Sensor Connected To
RTM ZONE TEMP INPUT 82.0 F
1. Pressing the NEXT key will display the following screen.
Temp Measured By Sensor Connected To
RTM SUPPLY AIR TEMP INPUT 50.0 F
1. Pressing the NEXT key will display the following screen.
(On units with a NSB zone sensor installed)
Temp Measured By Sensor Connected To
NSB Panel Temp Sensor Input 79.5 F
1. Pressing the NEXT key will display the following screen.
Temp Measured By Sensor Connected To
RTM AUX TEMP INPUT 62.0 F
1. Pressing the NEXT key will display the following screen.
Temp Measured By Sensor Connected To
RTM OUTSIDE AIR TEMP INPUT 86.0 F
1. Pressing the NEXT key will display the following screen.
STATUS
