Programming
PKG-SVP01B-EN
(On units with hydronic, electric, or external heat only)
Temp Measured By Sensor Connected To
HEAT MODULE AUX TEMP INPUT 82.0 F
1. Pressing the NEXT key will display the following screen.
(On units with a VCM and OA preheater enabled)
Temp Measured By Sensor Connected To
ECEM RETURN AIR TEMP INPUT 78.0 F
1. Pressing the NEXT key will display the following screen.
(On water-cooled units only)
Temp Measured By Sensor Connected To
WSM ENT WATER TEMP INPUT 60.1 F
1. Pressing the NEXT key will display the following screen.
(On water-cooled units only)
Temp Measured By Sensor Connected To
WSM MIXED AIR TEMP INPUT 51.7 F
1. Pressing the NEXT key will display the following screen.
(On water-cooled units only)
Temp Measured By Sensor Connected To
WSM ENT COND WATER TEMP INPUT 64.9 F
1. Pressing the NEXT key will display the following screen.
(On units with a VCM installed and O/A preheater enabled)
Temp Measured By Sensor Connected To
VCM MODULE AUX TEMP INPUT 50.0 F
1. Pressing the NEXT key will display the following screen.
Compressor Module Ckt 1
Evap Temp 75.0 Sat Cond Temp 81.0 F
1. Pressing the NEXT key will display the following screen.
Compressor Module Ckt 2
Evap Temp 72.0 Sat Cond Temp 87.0 F
1. Pressing the NEXT key will display the following screen.
STATUS
