Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN
51
Programming
Device Characteristic Setup Screens
(Applicable to units as noted)
Device Characteristics Setup Definitions
Press ENTER to Review or Adjust
1. Press the NEXT key to bypass this section or press the ENTER key to view the
following screens.
(On units with an airside economizer)
Actuator Setup OA Damper
Max Stroke Time 30 Sec
Factory Preset: 150 Seconds
Possible Values: 1-255 Seconds
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Actuator Setup OA Damper
Min Voltage 2.0 VDC
Factory Preset: 2.0 VDC
Possible Values: 0.0-9.9 VDC
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Actuator Setup OA Damper
Max Voltage 10.0 VDC
Factory Preset: 10.0 VDC
Possible Values: 0.1-10.0 VDC
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Actuator Setup OA Damper
Direct/Reverse Act DIRECT ACTING
Possible Values: Direct Acting, Reverse Acting
1. Pressing the NEXT key will display the following screen.
(On units with a waterside economizer)
Actuator Setup Water Economizer
Max Stroke Time 150 Sec
Factory Presets: 150 Sec
Possible Values: 1-255 Sec
1. Pressing the NEXT key will display the following screen.
Device Characteristic Setup
Definitions
To change device characteristic values
on a particular screen:
1. Press the plus or minus key until the
correct value appears in the screen.
2. Press the ENTER key to confirm your
choice. If you’ve made an error, press
the CANCEL key to delete your entry.
To navigate to another screen:
1. Press the NEXT key to advance to the
next screen, OR
a. if no further changes are required and
you want to exit back to view the unit
operating status, press the STATUS key
once, OR
b. if you want to remain in the Device
Characteristic Setup Definitions
submenu, press the SETUP key once
and it will return you to the beginning of
that particular submenu, OR
c. if you want to exit to another submenu
in the SETUP menu, press the SETUP
key twice. Then press the NEXT key to
scroll through the SETUP submenu
choices, OR
d. if you want to exit to another menu,
such as CONFIGURATION, press that
key once, then press the NEXT key to
scroll through those screens.
