Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN
59
Programming SETPOINT
(On units with an airside economizer)
Reference Enthalpy: Enable Air Econ
When OA Enthalpy is Below: 25 BTU/LB
Factory Presets: 25 BTU/LB
Possible Values: 19-28 BTU/LB
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Supply Air Low Limit - Modulate Economizer
Toward Min Pos if SA Temp Below: 50 F
Factory Presets: 50 F
Possible Values: 40-65 F
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Default OA Damper Min Position: 15 %
Factory Presets: 15%
Possible Values: 0-100%
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer, OA cfm compensation, and IGV or VFD
or on units without an economizer, with IGV or VFD, and a VCM)
Default OA Damper Min Position: 15 %
with IGV/VFD Command at Minimum (0 %)
Factory Presets: 15%
Possible Values: 0-100%
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer, OA cfm compensation, and IGV or VFD
or on units without an economizer, with IGV or VFD, and a VCM)
Default OA Damper Min Position: 10 %
with IGV/VFD Command at Maximum (100 %)
Factory Presets: 10%
Possible Values: 0-100%
1. Pressing the NEXT key will display the following screen.
(On units with a VCM)
Default Minimum OA Flow Setpoint: 40 CCFM
Min OA Flow Deadband: 10.0 CCFM
Possible Values: Setpoint = 0-max unit airflow
Deadband = 5.0-20 CCFM
1. Pressing the NEXT key will display the following screen.
