Trane IntelliPak Signature Series Programming Guide

60
Programming
PKG-SVP01B-EN
(On units with a VCM installed and preheat enabled)
Preheat Output ON If Preheat Temp Below
Preheat Activation Temperature: 35 F
Factory Presets: 35 F
Possible Values: 35-75 F
1. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD. Also, on units with SAT control without air
volume control and supply air pressure sensor installed)
Default Supply Air Pressure: 1.5 IWC
High Limit: 4.0 IWC Deadband: 0.5 IWC
Factory Presets: Setpoint = 1.5 IWC
High Limit = 4.0 IWC
Deadband = 0.5 IWC
Possible Values: Setpoint = 1.0-4.3 IWC
High Limit = 1.2-4.7 IWC
Deadband = 0.1-2.0 IWC
Note: The high limit setpoint cannot be adjusted below the parameters of the following
equation: The high limit = Deadband - 0.1 2
1. Pressing the NEXT key will display the following screen.
Low Ambient Comp Lockout Temp: 50 F
Comp (s) OFF If OA Temp Below This Value
Factory Presets: 50 F
Possible Values: -20-80 F
1. Pressing the NEXT key will display the following screen.
Setpoint Source Selections Submenu
Press ENTER to Review or Adjust
1. Pressing the NEXT key will display the following screen.
For Supply Air Temp Cooling Control, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
Factory Presets: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Menu
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
1. Pressing the NEXT key will display the following screen.
SETPOINT
