Trane IntelliPak Signature Series Programming Guide

PKG-SVP01B-EN
61
Programming
SETPOINT
(On units with hydronic or electric heat)
For Supply Air Temp Heating Control, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
Factory Presets: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu
GBAS 0-5 VDC Module
1. Pressing the NEXT key will display the following screen.
For Occ Zone Temp Cooling Control, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
Factory Presets: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Menu
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
1. Pressing the NEXT key will display the following screen.
(On units with hydronic or electric heat)
For Occ Zone Temp Heating Control, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
Factory Presets: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Menu
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
1. Pressing the NEXT key will display the following screen.
For Unocc Zone Temp Cooling Control, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
Factory Presets: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Menu
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
1. Pressing the NEXT key will display the following screen.
(On units with hydronic or electric heat)
For Unocc ZoneTemp Heating Control, Use
Setpoint From: HI (KEYPAD) SETPOINT MENU
Factory Presets: HI (Keypad) Setpoint Menu
Possible Values: HI (Keypad) Setpoint Menu
Zone Sensor Setpoint Menu
NSB Zone Sensor Setpoint Input
GBAS 0-5 VDC Module
1. Pressing the NEXT key will display the following screen.
