Trane Link UX360 User Manual

UX360 Smart Thermostat
18-HD98D1-1B-EN 15
Select Custom to
manually enter a sensor
name
Assign or Unassign
the sensor
Enable/Disable
temperature
Enable/Disable
humidity sensing
Select a custom or predefined sensor name
9.3 Assigning Sensors
To assign a sensor to the system:
1. Select the corresponding sensor under
Available Sensors.
2. On the Sensor Details screen, select
Assigned Status.
3. Select Assign and then Done.
4. The sensor will be assigned to the system and
removed from the Available Sensors list.
5. Up to four sensors can be assigned to the
system at a time.
9.4 Unassigning Sensors
To unassign a sensor:
1. Select the corresponding sensor under
Available Sensors.
2. On the Sensor Details screen, select
Assigned Status.
3. Select Unassign and then Done.
4. The sensor will be unassigned from the
system and will be added back to the
Available Sensors list.

Trane Link UX360 Specifications

General

Brand	Trane
Model	Link UX360
Category	Thermostat
Language	English
