UX360 Smart Thermostat
18-HD98D1-1B-EN 11
Sub Menu Menu Selection Options [Default] Description
Compressor
Cooling
System Control
More Efficient/Efficient/
Balanced/ Comfort/
[More Comfort]
Minimum CFM Per Ton 200-500 [250]
Maximum CFM Per Ton 200-500 [500]
Minimum value based on Minimum
CFM Per Ton setting. Maximum value
based on Comp Cooling Maximum
Airflow setting.
Cooling Maximum
Airflow (CFM)
[0] Range varies per system settings.
Compressor
Heating
Cycles Per Hour 2-6 CPH [3]
Blower Off Delay
[No delay]/30/60/90
seconds
Blower On Delay
[No delay]/15/30
seconds
Heating Maximum RPM [High]/Med/Low
System Control [Comfort]/Efficiency
Comp Heat CFM Per Ton
290-450 [400]
8.3 Energy
8.4 Environment
Sub Menu Menu Selection Options [Default] Description
Indoor Heat
Auxiliary Heat Lockout Enabled/[Disabled]
Enable auxiliary heat lockout
(10° minimum separation when
enabling auxiliary heat lockout and
compressor heat lockout).
Auxiliary Heat Lockout
Temp (°F)
32°F -70°F [45°F]
Select an outdoor temperature to
prevent auxiliary heat above the
selected outdoor temperature.
Compressor
Heating
Compressor Heat
Lockout
Enabled/[Disabled]
Enable compressor heat lockout (10°
minimum separation when enabling
auxiliary heat lockout and compressor
heat lockout)
Lockout Temperature
(°F)
5°F -70°F [30°F]
Select an outdoor temperature to
prevent compressor heating below the
selected outdoor temperature.
Outdoor Unit
Power Factor
Correction
Enabled/[Disabled]
Sub Menu Menu Selection Options [Default] Description
Outdoor Unit
Reduce Electrical
Interference
Enabled/[Disabled]
Defrost Termination
Temp (°F)
[Factory]/Medium/High
