6 BAS-SVX33F-EN
General Information
Dimensions
The following illustration provides specific dimension details.
Clearances
Clearances must be provided for air circulation, mounting the power supply module, and
connecting cables.The following illustration and table provide the recommended minimum
clearances.
24
24
VAC
VAC
XFMR
XFMR
OUT
OUT
24
24
VAC
VAC
2.4 in.
(6.14 cm)
2.4 in.
(6.1 cm)
1.8 in.
(4.5 cm)
4.0 in.
(10.2 cm)
2.4 in.
(6.1 cm)
1.2 in.
(3.1 cm)
0.6 in.
(1.5 cm)
2.0 in.
(5.0 cm)
2.0 in.
(5.0 cm)
PM014
24
VAC
XFMR
OUT
24
VAC
Vents
Vent clearance
Vent clearance
Vents
Clearance Measurement
Installing and operating
In accordance with local
electrical codes
Vent space 1.8 in. minimum (4.6 cm)
Note: The power supply vents must have adequate open space to
allow convective air flow to cool the unit.
1.8 in.
(4.6 cm)
1.8 in.
(4.6 cm)
