General Information
Specifications
The power supply module is in conformance with the physical, environmental, and electrical
specifications as listed in the following tables.
(a)The power supply output is UL 1310 class 2 and IEC60950-1 limited power source (LPS).
(b) Maximum required for 1.4 A DC loading.
Table 2. PM014 Specifications
Enclosure IP20 (NEMA 1)
DIN rail DIN 50022, 35 mm x 7.5 mm
Environmental Parameters:
• Storage temperature
-67°F (-55°C) minimum; 203°F (95°C) maximum
• Operating temperature
–40°F (–40°C) minimum; 158°F (70°C) maximum
• Humidity (non-condensing)
5% relative humidity (RH) minimum; 95% RH maximum
Electrical Parameters:
• Output voltage
(a)
22.8 Vdc minimum; 24 Vdc nominal; 25.2 Vdc maximum
• Output current
(a)
0 minimum; 1.4 Adc maximum
• Input voltage
18 Vac minimum; 24 Vac nominal; 32 Vac maximum; 50 or 60 Hz
• Input VA
20 VA minimum; 76 VA
(b)
