54 ARTC-SVX005A-EN
Chiller/Heater Performance Data
This manual uses a typical 120-ton water-cooled chiller/
heater consisting of four modules with brazed plate heat
exchangers and condensers for example purposes. (See
Table below) The model number and a chiller/heater’s
precise configuration can be found on the model
nameplate. See Figure 1, p. 7.
Table 12. PolyTherm chiller/heater example specifications
Chiller/Heater (Four 30-ton Modules (TPWCCMV0300T3-MM-HR-3HX)
Evaporator Type: Brazed plate Fluid: Water
Condenser: Brazed plate Fluid: Water
Source/Sink Hx: Brazed plate Fluid: 30% Glycol
Cooling Mode
Load Source/Sink Heat Exchanger
EFT = 55 °F (13 °C) LFT = 45 °F (7 °C) EFT = 65 °F (18 °C) LFT = 77 °F (25 °C)
Flow Rate: 600 gpm Flow Rate: 650 gpm
Pressure Drop: 3.8 psi Pressure Drop: 4.2 psi
Cooling Capacity: 3,480,000 btu/hr (290 tons)
Heating Mode
Load Source/Sink Heat Exchanger
EFT = 100 °F (38 °C) LFT = 120 °F (49 °C) EFT = 60 °F (16 °C) LFT = 50 °F (10 °C)
Flow Rate: 300 gpm Flow Rate: 424 gpm
Pressure Drop: 1.6 psi Pressure Drop: 2.4 psi
Cooling Capacity: 2,968,000 Btu/hr (870 kW)
Simultaneous Heating and Cooling Mode
Load (Cold) Load (Hot)
EFT = 55 °F (13 °C) LFT = 45 °F (7 °C) EFT = 100 °F (38 °C) LFT = 120 °F (49 °C)
Flow Rate: 476 gpm Flow Rate: 346 gpm
Pressure Drop: 2.7 psi Pressure Drop: 2.0 psi
Cooling Capacity: 2,380,000 Btu/hr (198.3 tons)
Heating Capacity: 3,480,000 Btu/hr (1,010 kW)
Key: Btu/hr = British Thermal Units per hour; EFT = Entering Fluid Temperature; gpm = gallons per minute; Hx = Heat
exchanger; kW = kilowatt; LFT = Leaving Fluid Temperature; psi = pounds per square inch.
