Table PD-3 — Heat Pump Reverse Cycle Heating Capacity (Btu)
Model No.
1
PTHC 07 PTHC 09 PTHC 12 PTHC 15
Voltage
3
208 230 265 208 230 265 208 230 265 208 230 265
Amps 3.0 2.6 2.2 3.6 3.2 2.6 5.1 4.5 3.9 6.3 5.7 5.4
Watts 550 570 570 730 740 740 1000 1020 1020 1355 1365 1365
Btuh
2
6200 6400 6400 8000 8100 8100 10600 10800 10800 13200 13300 13300
COP
2
3.3 3.3 3.3 3.2 3.2 3.2 3.1 3.1 3.1 2.9 2.9 2.9
CFM (Dry) 230 235 235 230 235 230 290 310 310 335 345 345
Heating
2
Btuh °F
Outdoor Ambient 62 7200 7400 7400 9600 9700 9700 12800 13000 13000 15700 15800 15800
57 6900 7100 7100 9100 9200 9200 12100 12300 12300 14900 15000 15000
52 6500 6700 6700 8500 8600 8600 11400 11600 11600 14100 14200 14200
Rating Point
2
47 6200 6400 6400 8000 8100 8100 10600 10800 10800 13200 13300 13300
42 5900 6100 6100 7500 7600 7600 9900 10100 10100 12400 12500 12500
37 5600 5800 5800 7000 7100 7100 9200 9400 9400 11600 11700 11700
32 5300 5500 5500 6500 6600 6600 8400 8600 8600 10700 10800 10800
27 5000 5200 5200 6000 6100 6100 7700 7900 7900 9900 10000 10000
24 4800 5000 5000 5700 5800 5800 7300 7500 7500 9400 9500 9500
Watts 62 585 600 600 790 800 800 1100 1120 1120 1455 1465 1465
Outdoor Ambient 57 580 595 595 780 790 790 1075 1090 1090 1430 1440 1440
52 560 575 575 755 765 765 1045 1060 1060 1395 1405 1405
Rating Point 47 555 570 570 730 740 740 1005 1020 1020 1355 1365 1365
42 535 560 560 710 720 720 970 985 985 1315 1325 1325
37 530 545 545 685 695 695 935 950 950 1275 1285 1285
32 520 535 535 670 680 680 885 900 900 1230 1240 1240
27 510 525 525 640 650 650 840 855 855 1180 1190 1190
24 505 520 520 620 630 630 815 830 830 1170 1180 1180
Notes:
1. All 265 volt models must use Trane’s subbase or Trane’s hard-wire junction box kit.
2. Heating capacity and efficiency is based on unit operation without condensate pump. Unit automatically switches to electric heat at 25°F outdoor coil temperature. Depending upon
relative humidity conditions, this will occur at approximately 35°F outdoor ambient temperature.
