Trane R Series Installation, Operation And Maintenance

Installation - Electrical
104 RTAC-SVX01J-EN
Analog Input, 84 Line 2 Current (%RLA)- Compressor 1A Line 2 Current (%RLA)- Compressor 1A
Analog Input, 85 Line 3 Current (%RLA)- Compressor 1A Line 3 Current (%RLA)- Compressor 1A
Analog Input, 86 Line 1 Current (%RLA)- Compressor 1B Line 1 Current (%RLA)- Compressor 1B
Analog Input, 87 Line 2 Current (%RLA)- Compressor 1B Line 2 Current (%RLA)- Compressor 1B
Analog Input, 88 Line 3 Current (%RLA)- Compressor 1B Line 3 Current (%RLA)- Compressor 1B
Analog Input, 89 Line 1 Current (%RLA)- Compressor 2A Line 1 Current (%RLA)- Compressor 2A
Analog Input, 90 Line 2 Current (%RLA)- Compressor 2A Line 2 Current (%RLA)- Compressor 2A
Analog Input, 91 Line 3 Current (%RLA)- Compressor 2A Line 3 Current (%RLA)- Compressor 2A
Analog Input, 92 Line 1 Current (%RLA)- Compressor 2B Line 1 Current (%RLA)- Compressor 2B
Analog Input, 93 Line 2 Current (%RLA)- Compressor 2B Line 2 Current (%RLA)- Compressor 2B
Analog Input, 94 Line 3 Current (%RLA)- Compressor 2B Line 3 Current (%RLA)- Compressor 2B
Analog Input, 95 Number of Circuits Number of Circuits
Analog Input, 96 Number of Compressors, Ckt 1 Number of Compressors, Ckt 1
Analog Input, 97 Number of Compressors, Ckt 2 Number of Compressors, Ckt 2
Multi-State Input, 1 Running Mode Indicates the primary running mode of the chiller.
Multi-State Input, 2 Operating Mode Indicates the primary operating mode of the chiller.
Multi-State Input, 3 MP Communication Status Communication status.
Multi-State Input, 4 Refrigerant Type Refrigerant type.
Multi-State Input, 5 Model Information Indicates the model type of the chiller.
Multi-State Input, 6 Cooling Type Cooling type of the condenser.
Multi-State Input, 7 Manufacturing Location Location where chiller was manufactured.
Binary Output, 1 Chiller Auto Stop Command Allows the chiller to run if conditions for running are met.
Binary Output, 2 Remote Diagnostic Reset Command Resets remotely diagnostics that can be reset.
Binary Output, 4 Noise Reduction Request Requests chiller to enter mode to reduce noise.
Binary Output, 1 Chiller Auto Stop Command Allows the chiller to run if conditions for running are met.
Binary Input, 1 Run Enabled Indicates if the chiller is available to run or is currently running.
Binary Input, 2 Local Setpoint Control
Indicates if the chiller is being controlled by local setpoints instead
of BAS setpoints.
Binary Input, 3 Capacity Limited
Indicates if conditions may exist that prevent the chiller from
reaching setpoint.
Binary Input, 4 Chiller Running State Indicates if the chiller is running or stopped.
Binary Input, 5 Condenser Water Flow Status Condenser water flow status.
Binary Input, 6 Maximum Capacity Indicates if all available chiller capacity is being used.
Binary Input, 7 Head Relief Request
Indicates if chiller is asking an outside system to provide more
heat.
Binary Input, 9 Compressor 1A Running Indicates if compressor 1A is running.
Binary Input, 10 Compressor 1B Running Indicates if compressor 1B is running.
Binary Input, 11 Compressor 2A Running Indicates if compressor 2A is running.
Binary Input, 12 Compressor 2B Running Indicates if compressor 2B is running.
Binary Input, 17 Evaporator Water Pump Request
Indicates a request from the chiller to turn on the evaporator
water pump.
Binary Input, 19 Condenser Water Pump Request
Indicates a request from the chiller to turn on the condenser
water pump.
Binary Input, 20 Noise Reduction Active Indicates if the chiller is in a state where noise is being reduced.
Binary Input, 22 Evaporator Water Flow Status Indicates if water is flowing through the evaporator.
Binary Input, 23 Alarm Present Indicates if an alarm is active.
Table 53. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) (continued)
Object
Identifier
(a)
Object Name Description
