Trane R Series Installation, Operation And Maintenance

Installation - Electrical
RTAC-SVX01J-EN 103
Analog Input, 27 Starts- Compressor 1B Number of starts for compressor 1B.
Analog Input, 28 Starts- Compressor 2A Number of starts for compressor 2A.
Analog Input, 29 Starts- Compressor 2B Number of starts for compressor 2B.
Analog Input, 34 Run Time- Compressor 1A Total run time of compressor 1A.
Analog Input, 35 Run Time- Compressor 1B Total run time of compressor 1B.
Analog Input, 36 Run Time- Compressor 2A Total run time of compressor 2A.
Analog Input, 37 Run Time- Compressor 2B Total run time of compressor 2B.
Analog Input, 42 Airflow Percentage- Circuit 1 Approximate airflow percentage of circuit 1.
Analog Input, 43 Airflow Percentage- Circuit 2 Approximate airflow percentage of circuit 2.
Analog Input, 44 Evaporator Entering Water Temp Temperature of the water entering the evaporator.
Analog Input, 45 Evaporator Leaving Water Temp Temperature of the water leaving the evaporator.
Analog Input, 46 Condenser Entering Water Temp Temperature of the water entering the condenser.
Analog Input, 47 Condenser Leaving Water Temp Temperature of the water leaving the condenser.
Analog Input, 48 High Side Oil Pressure- Compressor 1A Pressure of the oil at the high side of compressor 1A.
Analog Input, 49 High Side Oil Pressure- Compressor 1B Pressure of the oil at the high side of compressor 1B.
Analog Input, 50 High Side Oil Pressure- Compressor 2A Pressure of the oil at the high side of compressor 2A.
Analog Input, 51 High Side Oil Pressure- Compressor 2B Pressure of the oil at the high side of compressor 2B.
Analog Input, 56 Refrigerant Disch Temp- Ckt 1 Temperature of the refrigerant being discharged from Ckt 1.
Analog Input, 57 Outdoor Air Temperature Outdoor air temperature.
Analog Input, 58 Condenser Control Output Percentage of condenser water flow being requested by chiller.
Analog Input, 59 Phase AB Voltage- Compressor 1A Phase AB voltage, compressor 1A.
Analog Input, 60 Phase BC Voltage- Compressor 1A Phase BC voltage, compressor 1A.
Analog Input, 61 Phase CA Voltage- Compressor 1A Phase CA voltage, compressor 1A.
Analo5 Input, 62 Phase AB Voltage- Compressor 1B Phase AB voltage, compressor 1B.
Analog Input, 63 Phase BC Voltage- Compressor 1B Phase BC voltage, compressor 1B.
Analog Input, 64 Phase CA Voltage- Compressor 1B Phase CA voltage, compressor 1B.
Analog Input, 65 Phase AB Voltage- Compressor 2A Phase AB voltage, compressor 2A.
Analog Input, 66 Phase BC Voltage- Compressor 2A Phase BC voltage, compressor 2A.
Analog Input, 67 Phase CA Voltage- Compressor 2A Phase CA voltage, compressor 2A.
Analog Input, 68 Phase AB Voltage- Compressor 2B Phase AB voltage, compressor 2B.
Analog Input, 69 Phase BC Voltage- Compressor 2B Phase BC voltage, compressor 2B.
Analog Input, 70 Phase CA Voltage- Compressor 2B Phase CA voltage, compressor 2B
Analog Input, 71 Line 1 Current (in Amps)- Compressor 1A Line 1 Current (in Amps)- Compressor 1A
Analog Input, 72 Line 2 Current (in Amps)- Compressor 1A Line 2 Current (in Amps)- Compressor 1A
Analog Input, 73 Line 3 Current (in Amps)- Compressor 1A Line 3 Current (in Amps)- Compressor 1A
Analog Input, 74 Line 1 Current (in Amps)- Compressor 1B Line 1 Current (in Amps)- Compressor 1B
Analog Input, 75 Line 2 Current (in Amps)- Compressor 1B Line 2 Current (in Amps)- Compressor 1B
Analog Input, 76 Line 3 Current (in Amps)- Compressor 1B Line 3 Current (in Amps)- Compressor 1B
Analog Input, 77 Line 1 Current (in Amps)- Compressor 2A Line 1 Current (in Amps)- Compressor 2A
Analog Input, 78 Line 2 Current (in Amps)- Compressor 2A Line 2 Current (in Amps)- Compressor 2A
Analog Input, 79 Line 3 Current (in Amps)- Compressor 2A Line 3 Current (in Amps)- Compressor 2A
Analog Input, 80 Line 1 Current (in Amps)- Compressor 2B Line 1 Current (in Amps)- Compressor 2B
Analog Input, 81 Line 2 Current (in Amps)- Compressor 2B Line 2 Current (in Amps)- Compressor 2B
Analog Input, 82 Line 3 Current (in Amps)- Compressor 2B Line 3 Current (in Amps)- Compressor 2B
Analog Input, 83 Line 1 Current (%RLA)- Compressor 1A Line 1 Current (%RLA)- Compressor 1A
Table 53. All Object Types Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) (continued)
Object
Identifier
(a)
Object Name Description

Trane R Series Specifications

General

Brand	Trane
Model	R Series
Category	Chiller
Language	English
