Table 63. Configuration View Items
Tab Item Default Description
Feature Basic Product Line RTAC - Air Cooled Series R Chiller
Unit Nominal Capacity
120 Nominal Tons
130 Nominal Tons
140 Nominal Tons
155 Nominal Tons
170 Nominal Tons
185 Nominal Tons
200 Nominal Tons
225 Nominal Tons
250 Nominal Tons
275 Nominal Tons
300 Nominal Tons
350 Nominal Tons
375 Nominal Tons
400 Nominal Tons
450 Nominal Tons
500 Nominal Tons
Unit Voltage
A - 200V/60Hz/3Ph power
C - 230V/60Hz/3Ph power
J - 380V/60Hz/3Ph power
D - 400V/50Hz/3Ph power
4 - 460V/60Hz/3Ph power
5 - 575V/60Hz/3Ph power
Manufacturing Location
U - Water Chiller Business Unit - Pueblo
E - Epinal Business Unit -Charmes
Design Sequence XX - Factory/ABU Assigned
Unit Type
N - Standard Efficiency/Performance
H - High Efficiency/Performance
A - Extra Efficiency/Performance
Agency Listing
N - No agency listing
U - C/UL listing
Pressure Vessel Code
A - ASME pressure vessel code
C - Canadian code
D - Australian code
L - Chinese code
R - Vietnamese code
S - Special
Evaporator Temperature Range & Application Type
F - Standard Temperature with Freeze Protection
R - Rem Evap, Std Temp, No Freeze Protection
G - Low Temp, with Freeze Protection
Evaporator Configuration
N - Standard 2 pass arrangement, insulated
P -3 pass arrangement, insulated
Condenser Temperature Range
N - Standard ambient 25-115°F
H - High ambient 25-125°F
L - Low ambient 0-115°F
W - Wide ambient 0-125°F
Condenser Fin Material
1 - Standard aluminum slit fins
2 - Copper fins, non-slit fins
4 - Complete Coat aluminum fins
Feature Condenser Fan/Motor Configuration
T - Standard fans, TEAO motors
W - Low Noise fans
Compressor Motor Starter Type
X - Across-the-line
Y - Wye-delta closed transition
Incoming Power Line Connection
1 -Single point
2 -Dual point (1/ckt)
Power Line Connection Type
T - Terminals only
D - Non-fused disconnect switch(es)
C - Circuit Breaker(s), HACR-rated
Unit Operator Interface D -Dyna-View
