Controls Interface
122 RTAC-SVX01J-EN
Remote Interface
N - No remote interface
C - Tracer Comm 3 interface
B - BACnet communication interface
L -Lon Talk Communication interface (LCI)
Control Input Accessories/Options
N -No remote input
R -Remote leaving water temp setpoint
C -Remote current limit setpoint
B -Remote leaving temp setpoint and remote current limit setpoint
Control Output Accessories/Options
N -No output options
A -Alarm relay
C -Icemaking
D -Icemaking and alarm relay
Short Circuit Rating
0 - No short circuit withstand rating
5 -Default short circuit rating
6 - High amp short circuit rating
Control Panel Accessories
N - No convenience outlet
A - 15A 115V convenience outlet (60HZ)
Refrigerant Service Valves
0 - No suction services valves
1 - Suction service valves
Compressor Sound Attenuator Option
0 - No sound attenuator
1 - Factory installed sound attenuator
Appearance Options
N - No appearance options
A - Architectural louvered panels
C - Half Louvers
P - Painted unit
L - Painted unit with full louvered panels
H - Painted unit with half louvered panels
K - Painted unit with access guards
W - Painted w/access guards and half louvers
Features Installation Accessories
N - No installation accessories
R - Neoprene Isolators
F - Flanged water connection kit
G - Neoprene isolators and flange wtr conn kit
Factory Test 0 - No factory run test
Control, Label, and Literature
Language
E - English
G - Chinese
Special Order
X - Standard catalog configuration
S - Unit has special order feature
Custom Comm 3 ICS address 55 1-64 REM = C
Status Relay #1 J2-10,11,12 Alarm - Latching None, Alarm - Latching (Active diagnostic persistence latching), Alarm - Auto reset
(Active diagnostic persistence non-latching), Alarm (Active diagnostic persistence
latching or non-latching), Alarm Ckt1 (Active diagnostic persistence latching or non-
latching), Alarm Ckt2 (Active diagnostic persistence latching or non-latching),
Chiller Limit Mode (With 20 minute filter), Circuit 1 Running, Circuit 2 Running, Max
Capacity
COOP = A, D or X
Status Relay #2 J2-7,8,9 Chiller Running
Status Relay #3 J2-4,5,6 Maximum Capacity
Status Relay #4 J2-1,2,3 Chiller Limit Mode
Phase Unbalance Trip 30 10-50%
Phase Unbalance Grace Period 90 30-255 Sec
Maximum Acceleration Time 3 1-255 Sec
Starter Feature All Enabled Contactor Integrity Test, Phase Reversal Detect, Phase Unbalance Detect
External Chilled Water Setpoint
Detection
2-10 VD 2-10 VDC, 4-20 mA CIOP = C or B
External Current Limit Water
Setpoint Detection
2-10 VDC 2-10 VDC, 4-20 mA CIOP = C or B
Custom Unit Voltage 400 380,400,415 VOLT = D
Name-
plate
•The Model Number field contains the model number stored in the DynaView.
•The Confirm Code field contains the confirm code stored in the DynaView. The confirm code is a four-digit hex value that is a mathematical
calculation of the model number. This number has one to one correlation to a specific model number and is used to verify that the model
number was entered properly.
•The Serial Number field contains the serial number stored in the DynaView.
• This model number and confirmation code must be know when the main processor requires replacement.
