Trane R Series

General Data
16 RTAC-SVX01J-EN
Table 5. General Data - 60 hz units - high efficiency - SI
Size 140 155 170 185 200 225 250 275 300 350 400
Compressor
Screw
Quantity#2222233444 4
Nominal size
@60Hz
(tons) 70/70 85/70 85/85 100/85 100/100 70-70/85 85-85/85
70-70/
70-70
85-85/
85-85
85-85/
85/85
100-100/
100-100
Evaporator
Flooded
Water storage (L) 129 136 151 148 163 163 163 273 273 314 344
2 Pass arrangement
Min flow(L/s)13141514151515242425 29
Max flow(L/s)47505650565656878794107
Water conn(NPS-in)6666666888 8
3 Pass arrangement
Min flow (L/s) 9 9 10 9 10 10 10 16 16 17 19
Max flow(L/s)31343734373737585862 71
Water conn(NPS-in)4444444668 8
Condenser
Fin and tube
Qty of coils#4444488888 8
Coil length (mm)
4572/
4572
5486/
4572
5486/
5486
6400/
5486
6400/
6400
3657/
3657
3657/
3657
5486/
3657
6400/
3657
5486/
5486
6400/
6400
Coil height (mm) 1067 1067 1067 1067 1067 1067 1067 1067 1067 1067 1067
Number of rows # 192 192 192 192 192 192 192 192 192 192 192
Fins per foot(fpf)3333333333 3
Fan
Direct drive propeller
Quantity # 5/5 6/5 6/6 7/6 7/7 8/6 8/8 12/6 14/6 12/12 14/14
Diameter (mm) 762 762 762 762 762 762 762 762 762 762 762
Air per fan (m³/hr) 15628 15628 15628 15629 15631 16619 15634 16397 16317 15628 15631
Power/motor (kW) 1.12 1.12 1.12 1.12 1.12 1.12 1.12 1.12 1.12 1.12 1.12
Fan speed (rps) 19 19 19 19 19 19 19 19 19 19 19
Tip speedM/S45454545454545454545 45
General unit
HFC-134a
# refrig ckts#2222222222 2
% min load%15151515151515151515 15
Refrig charge (kg) 79/79 98/93 98/98 102/98 102/102 107/107 107/107 188/91 209/91 188/188 209/209
Oil charge (L) 5/5 5/5 5/5 7/5 7/7 7/7 7/7 8-8/7 9-9/7 8-8/8-8 9-9/9-9
Min ambient-std (°C) -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9
Min ambient-low (°C) -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8
1. Data containing information on two circuits is shown as follows: ckt 1/ ckt 2.
2. Minimum start-up/operating ambient is based on a 5 mph wind across the condenser.
3. RTAC units must only operate with refrigerant R-134a and Trane Oil 00048.
