Trane R Series

General Data
RTAC-SVX01J-EN 17
Table 6. General Data - 60 hz units - extra efficiency - SI
Size 140 155 170 185 200 250 275 300 350
Compressor
Quantity#22222334 4
Nominal size
@60Hz
(tons) 85/85 100/85 100/100 120/100 120/120 85-85/100
100-100/
100
85-85/85/
85
100-100/
100-100
Evaporator
Flooded
Water storage (L) 151 148 163 163 163 273 273 314 344
2 Pass arrangement
Min flow(L/s)1514151515242425 29
Max flow(L/s)5650565656878794107
Water conn(NPS-in)66666888 8
3 Pass arrangement
Min flow (L/s) 10 9 10 10 10 16 16 17 19
Max flow(L/s)3734373737585862 71
Water conn(NPS-in)44444668 8
Condenser
Fin and tube
Qty of coils#44488888 8
Coil length (mm) 5486/5486 6400/5486 6400/6400 3657/3657 4572/2743 5486/3657 6400/3657 5486/5486 6400/6400
Coil height (mm) 1067 1067 1067 1067 1067 1067 1067 1067 1067
Number of rows # 192 192 192 192 192 192 192 192 192
Fins per foot(fpf)33333333 3
Fan
Direct drive propeller
Quantity # 6/6 7/6 7/7 8/6 8/8 12/6 14/6 12/12 14/14
Diameter (mm) 762 762 762 762 762 762 762 762 762
Air per fan (m³/hr) 15628 15629 15631 16619 15634 16397 16317 15628 15631
Power/motor (kW) 1.12 1.12 1.12 1.12 1.12 1.12 1.12 1.12 1.12
Fan speed (rps) 19 19 19 19 19 19 19 19 19
Tip speedM/S4545454545454545 45
General unit
HFC-134a
# refrig ckts#22222222 2
% min load%1515151515151515 15
Refrig charge (kg) 98/98 102/98 102/102 107/107 107/107 188/91 209/91 188/188 209/209
Oil charge (L) 5/5 7/5 7/7 7/7 7/7 8-8/7 8-8/7 8-8/8-8 8-8/8-8
Min ambient-std (°C) -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9 -3.9
Min ambient-low (°C) -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8 -17.8
1. Data containing information on two circuits is shown as follows: ckt 1/ ckt 2.
2. Minimum start-up/operating ambient is based on a 5 mph wind across the condenser.
3. RTAC units must only operate with refrigerant R-134a and Trane Oil 00048.
